STARTING MOTOR
GSX1300R HAYABUSA 2009 (K9) USA (E03)
Starting motor diagram GSX1300R HAYABUSA 2009 (K9) USA (E03)
STARTING MOTOR GSX1300R HAYABUSA 2009 (K9) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
3110015H00
ref: 1
MOTOR ASSY,STARTING
€ 473.50
2
3113038300
ref: 2
BRUSH SUB ASSY,STARTING MOTOR
€ 12.50
3
3113227A01
ref: 3
HOLDER,BRUSH
€ 47.00
4
3113565010
ref: 4
SPRING
€ 3.00
5
3114338300
ref: 5
O RING
€ 3.50
6
3115049500
ref: 6
HOUSING ASSY,STARTING
€ 114.50
7
3115638300
ref: 7
O RING
€ 3.00
8
3117138300
ref: 8
BUSH,B
€ 5.50
9
3117238300
ref: 9
BUSHING
€ 4.00
10
3117515H00
ref: 10
FRAME,STARTER END
€ 78.00
11
3126444110
ref: 11
O RING
€ 8.00
12
3128188C00
ref: 12
BOLT
€ 8.50
13
0928024003
ref: 13
O RING(D:3,ID:24.5)
€ 2.00
14
0831000067
ref: 14
NUT
€ 2.50
15
0912806024
ref: 15
09103-06212
SCREW (6X25)
€ 2.50
16
0910306212
ref: 16
BOLT(6X25)
€ 2.50
17
083613506A
ref: 17
NUT
€ 2.00
