LEFT HANDLE SWITCH

GSX400S 1985 (F) GENERAL EXPORT (E01)

Left handle switch diagram GSX400S 1985 (F) GENERAL EXPORT (E01)

LEFT HANDLE SWITCH GSX400S 1985 (F) GENERAL EXPORT (E01)

LEFT HANDLE SWITCH GSX400S 1985 (F) GENERAL EXPORT (E01)

prices are in EUR

ref

part #

description

quantity

1

5721149510
ref: 1

GRIP,L

€ 26.50

2

5750049121
ref: 2

LEVER ASSEMBLY,CLUTCH

€ 49.50

3

5762049101
ref: 3

LEVER,CLUTCH

€ 28.50

4

5743149110
ref: 4

BOLT,LEVER PIVOT

€ 5.00

5

0831921065
ref: 5

NUT

€ 2.50

6

5744144400
ref: 6

ADJUSTER,CABLE

€ 5.50

7

5744244400
ref: 7

NUT,CABLE ADJUSTER LOCK

€ 4.00

8

0120406204
ref: 8

BOLT

€ 2.00

9

0832221064
ref: 9

WASHER

€ 2.00

10

3740045111
ref: 10

SWITCH ASSY,HA

€ 161.00

11

0211205257
ref: 11

SCREW

€ 2.00

12

3757145110
ref: 12

LEVER,STARTER

€ 19.00

13

3757345110
ref: 13

WASHER

€ 2.00

14

3757345110
ref: 14

WASHER

€ 2.00

15

0832211068
ref: 15

WASHER 6MM

€ 2.00

16

0940712402
ref: 16

CLAMP(L:120)

€ 3.00
