FRONT FENDER

GSXR600 2014 (L4) USA (E03)

Front fender diagram GSXR600 2014 (L4) USA (E03)

FRONT FENDER GSXR600 2014 (L4) USA (E03)

FRONT FENDER GSXR600 2014 (L4) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

5310047H10YGS
ref: 1

FENDER ASSY,FR(BLACK)

€ 89.50

2

0932009016
ref: 2

CUSHION

€ 2.50

3

0913906131
ref: 3

SCREW(6X16)

€ 4.00

4

0913906146
ref: 4

SCREW(6X16)

€ 3.00
