GEAR SHIFTING

ref

part #

description

quantity

1

2521101H00
ref: 1
25211-01H01

FORK,GEAR SHIF

€ 72.50

2

2523101H00
ref: 2
25231-01H01

FORK,GEAR SHIF

€ 74.00

3

2541135F00
ref: 3

SHAFT,GEAR SHIFT FORK NO.1

€ 18.00

4

0916006019A05
ref: 4
09160-06019

WASHER. FORK SH

€ 1.50

5

0924114001
ref: 5

PLUG

€ 2.00

6

2531001H00
ref: 6

CAM,GEAR SHIFT

€ 134.00

7

0422104089
ref: 7

PIN

€ 1.50

8

2531242F00
ref: 8
25312-42F01

BOLT,GEAR SHIF

€ 5.50

9

2538113E30
ref: 9

PLATE,GEAR SHIFT CAM

€ 30.00

10

0913606147A05
ref: 10
09136-06147

SCREW

€ 2.00

11

0926225006
ref: 11

BEARING(25X47X8)

€ 24.00

12

0926325018
ref: 12

BEARING(25X32X12)

€ 17.50

13

2535006G00
ref: 13

STOPPER,SHIFT CAM

€ 19.00

14

2535501H00
ref: 14

SPRING,GEAR SHIFT CAM STOPPER

€ 3.00

15

2535701H00
ref: 15

BOLT,SHIFT CAM STOPPER ARM

€ 3.00

16

2535801H00
ref: 16

SPACER,CAM STOPPER

€ 6.00

17

2551001H00
ref: 17

SHAFT,GEAR SHIFT

€ 77.00

18

2551206G10
ref: 18

PLATE,GEAR SHIFT CAM DRIVE

€ 20.00

19

2551901H00
ref: 19

WASHER,GEAR SHIFT SHAFT END

€ 3.00

20

2551801H00
ref: 20

SPRING,GEAR SHIFT PLATE RETURN

€ 2.00

21

2567101011
ref: 21

STOPPER,GEAR SHIFT ARM

€ 3.00

22

0912606014A05
ref: 22
09126-06014

SCREW,6X16

€ 2.00

23

0916014016
ref: 23

WASHER(14X29X0.8)

€ 1.50

24

0926314027
ref: 24

BEARING(14X20X12)

€ 11.00

25

0928314006
ref: 25

SEAL,OIL(14X22X6)

€ 6.50

26

0944420001
ref: 26

SPRING

€ 5.00

27

0918114167
ref: 27

SHIM(14X22X1)

€ 3.50

28

0833131146
ref: 28
08331-3114A

CIRCLIP

€ 2.00

29

2552001H00
ref: 29

ARM,GEAR SHIFT LINK

€ 62.50

30

2552501H00
ref: 30

ROD,GEAR SHIFT LINK

€ 32.00

31

2560001H00
ref: 31

LEVER ASSY,GEA

€ 106.50

32

2565220C00
ref: 32

RUBBER,GEAR SHIFT PEDAL

€ 8.00

33

2561703F00A05
ref: 33
25617-03F10

SHAFT,GEAR SHIFT LEVER

€ 10.50

34

2568101H00
ref: 34

BRACKET,GEAR SHIFT LEVER

€ 102.00

35

0910608167
ref: 35

BOLT(8X20)

€ 3.50

36

0914006025
ref: 36

NUT

€ 2.00

37

0916012011A05
ref: 37

WASHER(12.5X20X1)

€ 1.50

38

015000625A
ref: 38

BOLT

€ 2.50

39

0831000067
ref: 39

NUT

€ 2.50

40

083313112A
ref: 40

CIRCLIP

€ 2.00

41

3773001H00
ref: 41
37730-14J00

SENSOR ASSY,GE

€ 87.50

42

0928026007
ref: 42

O RING(D:2.4,ID:25.7)

€ 6.50

43

0910605023
ref: 43

BOLT(5X16)

€ 2.50
