REAR MASTER CYLINDER
GV1200GLF MADURA 1985 (F) USA (E03)
Rear master cylinder diagram GV1200GLF MADURA 1985 (F) USA (E03)
REAR MASTER CYLINDER GV1200GLF MADURA 1985 (F) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
6960005A01
ref: 1
NO PRODUCT DESCRIPTION AVAILABLE
€ 79.50
2
6960005810
ref: 2
69600-04810
PISTON/CUP SET
€ 42.50
3
5116270040
ref: 3
CIRCLIP
€ 3.00
4
6969100A00
ref: 4
BOOT
€ 3.50
5
6967005A00
ref: 5
ROD,PUSH
€ 12.50
6
6969305A00
ref: 6
NUT
€ 1.50
7
6969205A00
ref: 7
YOKE
€ 6.50
8
6968634200
ref: 8
O RING
€ 3.50
9
6967205A00
ref: 9
CONNECTOR
€ 4.50
10
0211204124
ref: 10
02112-0412A
SCREW
€ 1.50
11
0832121045
ref: 11
08321-0104A
LOCK WASHER
€ 2.00
12
0832221045
ref: 12
08322-0104A
WASHER
€ 5.00
13
0711008305
ref: 13
07130-0830A
BOLT, REAR (8X30)
€ 3.00
14
6974005A00
ref: 14
69740-24A01
TANK ASSEMBLY,RESERVOIR
€ 99.50
15
5966704700
ref: 15
DIAPHRAGM
€ 8.00
16
5966904710
ref: 16
69669-24A01
CAP
€ 12.00
17
6968904A00
ref: 17
SCREW
€ 2.00
18
0110706165
ref: 18
01500-0616A
BOLT 6X16
€ 2.00
19
0832121064
ref: 19
08321-0106A
WASHER,LOCK
€ 2.00
20
0832221064
ref: 20
08322-0106B
WASHER
€ 2.00
21
6973105A00
ref: 21
HOSE,RESERVOIR TANK
€ 3.00
22
0940016302
ref: 22
09400-16304
CLAMP
€ 4.50
23
6948005A02
ref: 23
HOSE,REAR BRAKE
€ 33.00
24
0936010017
ref: 24
BOLT UNION
€ 6.50
25
0916110009
ref: 25
WASHER(10X15X1.5)
€ 2.00
