HANDLE SWITCH

GZ250 MARAUDER 2010 (L0) USA (E03)

Handle switch diagram GZ250 MARAUDER 2010 (L0) USA (E03)

HANDLE SWITCH GZ250 MARAUDER 2010 (L0) USA (E03)

HANDLE SWITCH GZ250 MARAUDER 2010 (L0) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3720013FB0
ref: 1

SWITCH ASSY RH

€ 45.00

2

D21160530B
ref: 2

SCREW

€ 0.00

3

D21160550B
ref: 3

SCREW

€ 0.00

4

021120510B
ref: 4

SCREW

€ 2.00

5

3740013FB0
ref: 5

SWITCH ASSY, HANDLE LH

€ 75.50

6

D21160525B
ref: 6

SCREW

€ 0.00

7

D21160545B
ref: 7

SCREW

€ 0.00
