HANDLEBAR

LS650 BOULEVARD S40 2008 (K8) USA CALIFORNI CANADA (E03 E33 E28)

Handlebar diagram LS650 BOULEVARD S40 2008 (K8) USA CALIFORNI CANADA (E03 E33 E28)

prices are in EUR

ref

part #

description

quantity

5611024C00
ref: 1

HANDLEBAR

€ 0.00

2-1

5650045C40
ref: 2-1
56500-45C41

MIRROR ASSY, REAR VIEW RH

€ 28.50

2-2

5650045C41
ref: 2-2

MIRROR ASSY,RR VIEW,R

€ 28.50

3-1

5660045C40
ref: 3-1

MIRROR ASSY,RH

€ 103.50

3-2

5660045C41
ref: 3-2

MIRROR ASSY,RR VIEW,L

€ 103.50

5820024C00
ref: 4

CABLE ASSY,CLUTCH

€ 36.00

5830024C00
ref: 5

CABLE ASSY,THROTTLE

€ 38.50

0214205087
ref: 6

SCREW

€ 2.00

5862024B00
ref: 7

CLAMP,STOP LAMP SWITCH CABLE

€ 4.50

015700616B
ref: 8

BOLT

€ 2.50

5883024B01
ref: 9

CABLE,STOP LAMP SWITCH

€ 24.00

0940408418
ref: 10

CLAMP(L:65)

€ 3.50

0940714407
ref: 11

CLAMP(L:145)

€ 4.00

5862124C00
ref: 12

GUIDE,CABLE

€ 0.00

0913905033
ref: 13

SCREW(5X10)

€ 2.00
