SEAT

LS650 BOULEVARD S40 2008 (K8) USA CALIFORNI CANADA (E03 E33 E28)

Seat diagram LS650 BOULEVARD S40 2008 (K8) USA CALIFORNI CANADA (E03 E33 E28)

prices are in EUR

ref

part #

description

quantity

SEAT ASSY

€ 0.00

4514924B00
ref: 2

CUSHION,SEAT

€ 0.00

4511624B00
ref: 3

CUSHION,CTR FR

€ 5.00

4514943500
ref: 4

CUSHION,SEAT

€ 3.00

4511424B00
ref: 5

BRACKET,SEAT RR

€ 6.00

4511824B00
ref: 6

CUSHION,SEAT RR BRACKET

€ 2.50

0916006066
ref: 7

WASHER(6.5X20X1.6)

€ 2.00

015500625B
ref: 8

BOLT

€ 2.50

015500612B
ref: 9

BOLT

€ 2.50

4511924B00
ref: 10

PLATE,SEAT HOOK FR

€ 2.00

4514924BA0
ref: 11

CUSHION,SEAT RR

€ 0.00

0913906115
ref: 12

SCREW(6X12)

€ 4.50

all assemblies
