TAIL LAMP (E2, E24)

ref

part #

description

quantity

1-1

3571040510
ref: 1-1
MODEL T

LAMP ASSY, TAIL

€ 0.00

1-2

3571040511
ref: 1-2
MODEL X

LAMP ASSY, TAIL

€ 0.00

2

3571230410
ref: 2

LENS

€ 15.50

3

0947106009
ref: 3

BULB(6V17/5.3W,STANLEY,A4813)

€ 6.50

4

3572340610
ref: 4

SCREW,REAR COMBINATION LAMP LENS

€ 0.00

5

0918006011
ref: 5

SPACER (6.1X9X9)

€ 2.00

6

0916006007
ref: 6

WASHER

€ 2.00

7

0831011068
ref: 7

NUT

€ 2.50

8

3597030910
ref: 8
E2

REFLEX REFLECTOR,RR

€ 47.50

9

0832121058
ref: 9
E2

LOCK WASHER

€ 2.00

10

0831011058
ref: 10
E2

NUT

€ 2.50

11

3597440620
ref: 11
MODEL T:E2

BRACKET

€ 0.00

12

0110706128
ref: 12
MODEL T:E2

BOLT

€ 2.00

13

0832221068
ref: 13
MODEL T:E2

WASHER

€ 2.00

14

0831011068
ref: 14
MODEL T:E2

NUT

€ 2.50

15

3597440640
ref: 15
MODEL X:E2

BRACKET

€ 3.00

16

0110405128
ref: 16
MODEL X:E2

BOLT

€ 2.00

17

0832221058
ref: 17
MODEL X:E2

WASHER

€ 2.50

18

0831011058
ref: 18
MODEL X:E2

NUT

€ 2.50

all assemblies
