EXHAUST VALVE (MODEL R)
RG125FU 1992 (N) (E02 E04)
Exhaust valve (model r) diagram RG125FU 1992 (N) (E02 E04)
EXHAUST VALVE (MODEL R) RG125FU 1992 (N) (E02 E04)
×
prices are in EUR
ref
part #
description
quantity
1
3397019D10
ref: 1
ACTUATOR ASSY
€ 546.00
2
0911606025
ref: 2
BOLT(6X25)
€ 2.50
3
1126920A04
ref: 3
PULLEY,CONTROLLER
€ 32.00
4
0712005203
ref: 4
BOLT
€ 2.00
5-1
1120619D00
ref: 5-1
VALVE ASSY, EXHAUST RH
€ 183.00
5-2
1120619D10
ref: 5-2
E34
VALVE ASSY, EXHAUST RH
€ 199.50
6-1
1120719D00
ref: 6-1
VALVE ASSY, EXHAUST LH
€ 176.50
6-2
1120719D10
ref: 6-2
E34
VALVE ASSY, EXHAUST LH
€ 174.50
7
0944003011
ref: 7
SPRING
€ 4.00
8
1127422D01
ref: 8
RETAINER,EXHAUST VALVE SPRING
€ 8.50
9
0214215123
ref: 9
SCREW
€ 2.00
10
1126308D11
ref: 10
SPACER,EXHAUST VALVE
€ 13.00
11
1125819D00
ref: 11
SHAFT,EXHAUST VALVE
€ 29.00
12
1126400B23
ref: 12
ARM,EXHAUST VALVE SHAFT
€ 17.00
13
0913406013
ref: 13
SCREW(6X10)
€ 4.50
14
0930008016
ref: 14
INCLUDED CYLINDER
BUSH(8X12X7)
€ 3.50
15
1126512C00
ref: 15
BUSH,EXHAUST VALVE NO.2
€ 8.50
16
1128312C00
ref: 16
SPACER,EXHAUST VALVE SHAFT
€ 5.50
17
1125301B31
ref: 17
PIN,EXHAUST VALVE 48.5MM
€ 20.50
18
1126519D00
ref: 18
HOLDER,EXHAUST VALVE
€ 28.50
19
1123919D00
ref: 19
SPACER, HOLDER BASE
€ 13.00
20
0928208001
ref: 20
SEAL,OIL(8X16X5)
€ 3.00
21
1125903D01
ref: 21
COVER,HOLDER
€ 19.00
22
0910806115
ref: 22
BOLT,STUD
€ 0.00
23
0142106408
ref: 23
STUD BOLT
€ 2.50
24
0831610063
ref: 24
NUT
€ 2.50
25
1126703D00
ref: 25
LEVER,EXHAUST VALVE
€ 6.00
26
1128503D00
ref: 26
SPRING,EXHAUST VALVE LEVER
€ 6.00
27
1126803D00
ref: 27
SPACER,EXHAUST VALVE PULLEY
€ 9.00
28
1126619D00
ref: 28
PULLEY,EXHAUST VALVE
€ 18.00
29
0911805005
ref: 29
BOLT(5X12)
€ 4.00
30
1127619D01
ref: 30
CABLE,EXHAUST VALVE NO.1
€ 14.50
31
1127719D01
ref: 31
CABLE,EXHAUST VALVE NO.2
€ 14.50
31
1126803D00
ref: 31
SPACER,EXHAUST VALVE PULLEY
€ 9.00
32
1126619D00
ref: 32
PULLEY,EXHAUST VALVE
€ 18.00
33
0911805005
ref: 33
BOLT(5X12)
€ 4.00
34
1127619D01
ref: 34
CABLE,EXHAUST VALVE NO.1
€ 14.50
35
1127719D01
ref: 35
CABLE,EXHAUST VALVE NO.2
€ 14.50
