REAR COMBINATION LAMP
RG125FU 1992 (N) (E02 E04)
Rear combination lamp diagram RG125FU 1992 (N) (E02 E04)
REAR COMBINATION LAMP RG125FU 1992 (N) (E02 E04)
×
prices are in EUR
ref
part #
description
quantity
1
3571022D00
ref: 1
LAMP ASSY,RR C
€ 86.00
2
3574022D00
ref: 2
LAMP UNIT
€ 45.50
3
3571822D00
ref: 3
SOCKET,RR COMB
€ 24.00
4
0947112083
ref: 4
BULB(12V21/5W)
€ 6.00
5
0918006044
ref: 5
SPACER (6.1X8X9.5)
€ 2.50
6
0932008048
ref: 6
CUSHION
€ 3.00
7
0916006056
ref: 7
WASHER(6.5X18X1)
€ 2.00
8-1
0831616064
ref: 8-1
MODEL N/P
NUT 6MM
€ 2.50
8-2
0831610063
ref: 8-2
MODEL R
NUT
€ 2.50
9
3592744110
ref: 9
PLATE,RR LICENSE
€ 22.50
10-1
0111706165
ref: 10-1
MODEL N
BOLT
€ 2.50
10-2
0111406166
ref: 10-2
MODEL P/R
BOLT
€ 2.50
11
0916006059
ref: 11
WASHER,COVER,FRONT
€ 2.00
12
0831626066
ref: 12
NUT
€ 2.00
13
0932106013
ref: 13
CUSHION
€ 2.50
14
3597000A21
ref: 14
REFLECTOR ASSEMBLY,REAR
€ 22.00
15-1
0831011056
ref: 15-1
MODEL N/P
NUT
€ 2.50
15-2
0831610053
ref: 15-2
MODEL R
NUT
€ 2.50
16
0832211056
ref: 16
WASHER
€ 2.00
17-1
3597448511
ref: 17-1
MODEL N
BRACKET,RR REFLEX REFLECTOR
€ 4.50
17-2
3597419D10
ref: 17-2
MODEL P/R
BRACKET, REAR REFLECTOR
€ 0.00
18-1
0214216165
ref: 18-1
MODEL N/P
SCREW, BRACKET
€ 2.00
18-2
0214206123
ref: 18-2
MODEL R
SCREW 6X12
€ 2.00
19
0916906031
ref: 19
WASHER
€ 2.00
20
0831012066
ref: 20
NUT
€ 2.00
