prices are in EUR
ref
part #
description
quantity
1-1
VALVE,EXHAUST,LOWER,RIGHT
1-2
VALVE,EXHAUST,LOWER,RIGHT
2-1
VALVE,EXHAUST,LOWER,LEFT
3
GUIDE SET,EXHAUST VALVE
4-1
STOPPER,EXHAUST VALVE
4-2
STOPPER,EXHAUST VALVE NO.2
5
SCREW
6
SPACER,EXHAUST VALVE
7
PIN,EXHAUST VALVE 48.5MM
8-1
VALVE,EXHAUST,MIDDLE,RIGHT
8-2
VALVE,EXHAUST MIDDLE RH
9-1
VALVE,EXHAUST,MIDDLE,LEFT
9-2
VALVE,EXHAUST MIDDLE LH
10
SPRING
12
ARM,EXHAUST VALVE SHAFT
13
SCREW(6X10)
14
CAP,EXHAUST VALVE
15
O RING(D:1.9,ID:22.6)
16
RETAINER,EXHAUST VALVE
17-2
BOLT
18
SPRING
19
SPACER,EXHAUST VALVE SPRING
20-1
SCREW
20-2
BOLT
21
WASHER
22
LEVER,EXHAUST VALVE NO.2
23
SPRING
24
SPACER,EXHAUST VALVE
25
LEVER,EXHAUST VALVE NO.1
26
BOLT(5X12)
27
GOVERNOR ASSY,EXHAUST VALVE
28
BEARING(10X22X2.8)
29
ACTUATOR,EXHAUST VALVE
30
BALL
31
STARTER,EXHAUST VALVE ACTUATOR
32
SCREW(5X10)
33
CIRCLIP
34
SHIM(19.1X25X0.3)
35
WASHER
36
BEARING(8X22X7)
37
ROD,EXHAUST VALVE
38
BUSH,EXHAUST VALVE ROD NO.1
39
BUSH,EXHAUST VALVE ROD NO.2
