CRANK BALANCER

SP500 1982 (Z) USA (E03)

Crank balancer diagram SP500 1982 (Z) USA (E03)

CRANK BALANCER SP500 1982 (Z) USA (E03)

CRANK BALANCER SP500 1982 (Z) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1265137400
ref: 1

BALANCER,CRANKSHAFT

€ 65.00

2

0926220057
ref: 2
09262-20106

BEARING

€ 20.50

3

1265937400
ref: 3

RETAINER,CRANK BAL BEARING

€ 2.00

4

0211206128
ref: 4
02112-06127

SCREW 6X12

€ 2.00

5

1266537452
ref: 5
12665-37453

SPROCKET,BALANCER DRIVE

€ 32.50

6

1267537452
ref: 6
12675-37453

SPROCKET,BALANCER DRIVE

€ 35.50

7

0915910014
ref: 7
09159-10046-XC0

NUT

€ 2.00

8

0834131039
ref: 8

KEY

€ 2.00
