CAM SHAFT / VALVE
SV650 1999 (X) USA (E03)
Cam shaft / valve diagram SV650 1999 (X) USA (E03)
CAM SHAFT / VALVE SV650 1999 (X) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1271020F00
ref: 1
CAMSHAFT,INTAKE FR
€ 186.50
2
1272020F00
ref: 2
CAMSHAFT,EXHAUST FR
€ 255.00
3
1273020F00
ref: 3
CAMSHAFT,INTAKE RR
€ 185.00
4
1274020F00
ref: 4
CAMSHAFT,EXHAUST RR
€ 255.00
5
1280005820
ref: 5
12800-05830
SHIM SET,TAPPET
€ 846.50
6
9900069491
ref: 6
CASE,TAPPET SHIM
€ 89.00
7
1291146E00
ref: 7
VALVE,INTAKE
€ 81.50
8
1291220F00
ref: 8
VALVE,EXHAUST
€ 38.00
9
1292033E10
ref: 9
SPRING SET,VALVE
€ 14.00
10
1293133E10
ref: 10
RETAINER,VALVE SPRING
€ 15.50
11
1293339E00
ref: 11
SEAT,VALVE SPRING
€ 5.50
12
0928904002
ref: 12
SEAL,OIL(4.5X10X8)
€ 7.50
13
1293217E50
ref: 13
COTTER VALVE
€ 2.50
14
1289117E00
ref: 14
TAPPET
€ 55.00
15-1
1289205C00120
ref: 15-1
SHIM,TAPPET
€ 7.00
15-10
1289205C00165
ref: 15-10
SHIM,TAPPET
€ 7.50
15-11
1289205C00170
ref: 15-11
SHIM,TAPPET
€ 7.50
15-12
1289205C00175
ref: 15-12
SHIM,TAPPET
€ 7.00
15-13
1289205C00180
ref: 15-13
SHIM,TAPPET
€ 7.50
15-14
1289205C00185
ref: 15-14
SHIM,TAPPET
€ 7.00
15-15
1289205C00190
ref: 15-15
SHIM,TAPPET
€ 7.00
15-16
1289205C00195
ref: 15-16
SHIM,TAPPET
€ 7.00
15-17
1289205C00200
ref: 15-17
SHIM,TAPPET
€ 7.00
15-18
1289205C00205
ref: 15-18
SHIM,TAPPET
€ 7.00
15-19
1289205C00210
ref: 15-19
SHIM,TAPPET
€ 7.00
15-2
1289205C00125
ref: 15-2
SHIM,TAPPET
€ 7.00
15-20
1289205C00215
ref: 15-20
SHIM,TAPPET
€ 7.00
15-21
1289205C00220
ref: 15-21
SHIM,TAPPET
€ 7.00
15-3
1289205C00130
ref: 15-3
SHIM,TAPPET
€ 7.00
15-4
1289205C00135
ref: 15-4
SHIM,TAPPET
€ 7.50
15-5
1289205C00140
ref: 15-5
SHIM,TAPPET
€ 7.50
15-6
1289205C00145
ref: 15-6
SHIM,TAPPET
€ 7.50
15-7
1289205C00150
ref: 15-7
SHIM,TAPPET
€ 7.50
15-8
1289205C00155
ref: 15-8
SHIM,TAPPET
€ 7.50
15-9
1289205C00160
ref: 15-9
SHIM,TAPPET
€ 7.50
