SEAT TAIL BOX (MODEL K3)

TL1000R 2001 (K1) USA (E03)

Seat tail box (model k3) diagram TL1000R 2001 (K1) USA (E03)

SEAT TAIL BOX (MODEL K3) TL1000R 2001 (K1) USA (E03)

SEAT TAIL BOX (MODEL K3) TL1000R 2001 (K1) USA (E03)

prices are in EUR

ref

part #

description

quantity

1-1

4550002FD00JW
ref: 1-1

BOX ASSY,SEAT TAIL(WHITE)

€ 0.00

1-2

4550002FD0YU9
ref: 1-2

BOX ASSY,SEAT TAIL(YELLOW)

€ 0.00

2

6816002FD0019
ref: 2

TAPE SET,BOX SEAT TAIL

€ 0.00

2

6816002FD0019
ref: 2

TAPE SET,BOX SEAT TAIL

€ 0.00
