FRAME - OIL TANK

TM250 1972 1973 1974 1975 (J) (K) (L) (M) USA (E03)

Frame - oil tank diagram TM250 1972 1973 1974 1975 (J) (K) (L) (M) USA (E03)

prices are in EUR

ref

part #

description

quantity

0214206127
ref: 4

SCREW 6X12

€ 1.50

5-1

0946200055A
ref: 5-1

BAND

€ 4.00

0832101067
ref: 8

WASHER,LOCK

€ 2.50

0916906010
ref: 9

WASHER

€ 3.00

0150006127
ref: 10

BOLT

€ 2.00

0214206127
ref: 11

SCREW 6X12

€ 1.50

6817126000
ref: 13

EMBLEM,CCIS

€ 4.00

093515080300B
ref: 15

HOSE(5X8X2000)

€ 10.00

0940108401
ref: 16

CLIP

€ 1.50

5122151010
ref: 17

CAP, OIL TANK

€ 3.50

5122216500
ref: 18

GASKET,OIL TANK CAP (NAS)

€ 3.50

0940108401
ref: 19

CLIP

€ 1.50

0940709301
ref: 20

CLAMP

€ 6.00

5122216500
ref: 21

GASKET,OIL TANK CAP (NAS)

€ 3.50

0932010008
ref: 22

CUSHION

€ 2.50

0918006310
ref: 23

SPACER(6.5X10X10)

€ 2.00

0150006207
ref: 24

BOLT

€ 2.00

0832101067
ref: 25

WASHER,LOCK

€ 2.50

0916006077
ref: 26

WASHER(6.5X20X1.2)

€ 2.00

FRAME - OIL TANK

all assemblies
