prices are in EUR
ref
part #
description
quantity
1
SWING ARM ASSEMBLY,REAR
2
SWING ARM ASSEMBLY,REAR
3
SWING ARM ASSEMBLY,REAR
4-1
BUSHING
4-2
BUSHING
5-1
SPACER,SWING ARM,CENTER
5-2
SPACER,SWING ARM,CENTER
6
NIPPLE,GREASE
7-1
SHAFT,REAR SWING ARM
8-2
NUT
9
NUT
10-1
WASHER
10-2
WASHER
11-1
SPACER,RR SWGARM PIVOT
11-2
SPACER,REAR SWING ARM
12-1
COVER,SWGARM BUSH DUST SEAL
12-2
COVER
13-1
O RING(D:2,ID:24.5)
13-2
O RING(D:3,ID:29.5)
14-1
WASHER(12.5X24X2.3)
14-2
WASHER(14.5X29X2.3)
19
LOCK WASHER
20-1
NO PRODUCT DESCRIPTION AVAILABLE
20-2
NO PRODUCT DESCRIPTION AVAILABLE
21-2
TENSIONER,CHAIN
22
SPACER
23
ROLLER,CHAIN GUIDE
24
SPACER(6.5X12X6.9)
25
BOLT
26
LOCK WASHER
27
WASHER
28-2
NUT (6MM)
29
ABSORBER ASSEMBLY,REAR SHOCK
30
ABSORBER ASSEMBLY,REAR SHOCK
31
ABSORBER ASSEMBLY,REAR SHOCK
32
ABSORBER ASSEMBLY,REAR SHOCK
33
NUT
34
WASHER
35
WASHER
36
WASHER,LOCK
39
LOCK WASHER
40
WASHER
41-1
WASHER (6.5X29X1.6)
41-2
WASHER (6.5X24X1.6)
43
BOLT(12X33)
44
LOCK WASHER
45
WASHER
46-1
WASHER (6.5X29X1.6)
46-2
WASHER (6.5X24X1.6)
47-1
TORQUE LINK,REAR
47-2
TORQUE LINK,REAR
48-1
BOLT, REAR TORQUE LINK
48-2
BOLT(8X22.5)
49
NUT
50
LOCK WASHER
51-1
RETAINER,SNAP
51-2
CLIP
52-2
BOLT(10X32.5)
54
LOCK WASHER
55
WASHER (12.5X24X1.6)
56-1
SPRING,RETAINER
56-2
CLIP
57
BUFFER,CHAIN TOUCH DEFLECTOR
