HEADLAMP HOUSING
TS400 1977 (B) USA (E03)
Headlamp housing diagram TS400 1977 (B) USA (E03)
HEADLAMP HOUSING TS400 1977 (B) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
5181030000
ref: 1-1
HOUSING,HEADLAMP
€ 72.00
1-2
5181027300126
ref: 1-2
51810-27300-737
HOUSING COMP,HEADLAMP
€ 54.00
1-3
5181027300291
ref: 1-3
51810-27300-737
HOUSING COMP,HEADLAMP
€ 54.00
2
5182127301
ref: 2
SPACER, HOUSING RH
€ 9.00
3
5182227301
ref: 3
SPACER, HOUSING LH
€ 9.00
4
5182727301
ref: 4
51827-27302
CUSHION,HEADLAMP HOUSING
€ 3.00
5
5184531031
ref: 5
GROMMET,HEADLAMP HOUSING
€ 4.00
5
5184531031
ref: 5
GROMMET,HEADLAMP HOUSING
€ 4.00
6
0223105128
ref: 6
02122-05127
SCREW(5X12)
€ 2.50
7
0122108207
ref: 7
01204-08207
BOLT
€ 3.00
8
0832121088
ref: 8
08321-01087
LOCK WASHER
€ 2.00
9
0832211088
ref: 9
08322-01087
WASHER
€ 2.00
10
0925040001
ref: 10
CAP
€ 2.50
