prices are in EUR
ref
part #
description
quantity
0
GEAR & CASE SET,FINAL BEVEL
0
GEAR & CASE SET,FINAL BEVEL
1
GEAR & CASE SET,FINAL BEVEL
2
STOPPER,FINAL DRIVE BEARING
3
PLATE,BEARING STOPPER
4
PLATE,BEARING STOPPER
5
O RING(D:1.9,ID:61.6)
7
BEARING(17X32X16)
8
WASHER(16X29X4)
9
NUT
10
SEAL,OIL(38X54X6)
11-1
SHIM,FINAL DRIVE GEAR
11-2
SHIM,FINAL DRIVE GEAR
11-3
SHIM,FINAL DRIVE GEAR
11-4
SHIM,FINAL DRIVE GEAR
11-5
SHIM,FINAL DRIVE GEAR
12
BOLT,STUD
13
WASHER
14
NUT
15
BEARING(70X110X13)
16-1
SHIM,DRIVEN GEAR BEARING T0.35
16-2
SHIM,DRIVEN GEAR BEARING T.040
16-3
SHIM,DRIVEN GEAR BEARING T0.50
16-4
SHIM,DRIVEN GEAR BEARING T0.60
17
PLATE,FINAL DRIVEN BRG OIL
18
SEAL,OIL(70X96X16)
19
BEARING(32X46X17.7)
20-1
SHIM,FINAL DRIVEN GEAR
20-2
SHIM,FINAL DRIVEN GEAR
20-3
SHIM,FINAL DRIVEN GEAR
20-4
SHIM,FINAL DRIVEN GEAR
20-5
SHIM,FINAL DRIVEN GEAR
20-6
SHIM,FINAL DRIVE GEAR
20-7
SHIM,FINAL DRIVE GEAR
20-8
SHIM,FINAL DRIVE GEAR
21
RETAINER,FINAL DRIVEN GEAR BRG
22
SCREW 6X12
23
SEAL,OIL(30X42X7)
24-2
CASE,FINAL
25
BOLT,STUD
26
CASE,FINAL GEAR BEARING
27
O RING(D:3.5,ID:131.6)
28
BOLT
29
PLUG
30
O RING(D:2.4,ID:17.8)
32
GASKET(14X19.2X2) (NAS)
33
COUPLING,FINAL DRIVE GEAR
34-1
YOKE COMP,UNIVERSAL JOINT
34-2
YOKE COMP,UNIVERSAL JOINT
35
SHAFT,PROPELLER
36
SPRING
37
SEAL,OIL(28.4X48X15)
38
CIRCLIP
