REAR FENDER

DR-Z125 2008 (K8) USA (E03) DRZ125 DR Z125

Rear fender diagram DR-Z125 2008 (K8) USA (E03) DRZ125 DR Z125

REAR FENDER DR-Z125 2008 (K8) USA (E03) DRZ125 DR Z125
REAR FENDER DR-Z125 2008 (K8) USA (E03) DRZ125 DR Z125
REAR FENDER DR-Z125 2008 (K8) USA (E03) DRZ125 DR Z125
prices are in EUR
ref
part #
description
quantity
1-1
6311308G50YU1
ref: 1-1
FENDER,RR
6311308G50YU1
€ 54.00
1-2
6311308G50019
ref: 1-2
FENDER,RR
€ 67.00
2
0910306200
ref: 2
BOLT(6X16)
€ 2.50
3
0916906076
ref: 3
WASHER
0916906076
€ 2.50
4
0916908045
ref: 4
WASHER
0916908045
€ 2.00
5
6341129F00
ref: 5
MUDGUARD,RR FENDER FR
6341129F00
€ 10.00
6
0913205053
ref: 6
SCREW(5X16)
0913205053
€ 2.50
7
0916906045
ref: 7
09169-06055
WASHER
0916906045
€ 2.50
8-1
6817108G60GY8
ref: 8-1
EMBLEM,125,R
€ 9.00
8-2
6817108G60BJB
ref: 8-2
EMBLEM,125,R
€ 9.00
9-1
6817208G60GY8
ref: 9-1
EMBLEM,125,L
€ 9.00
9-2
6817208G60BJB
ref: 9-2
EMBLEM,125,L
€ 9.00
10-1
6817108G70GY8
ref: 10-1
EMBLEM,125L,R
€ 11.50
10-2
6817108G70BJB
ref: 10-2
EMBLEM,125L,R
€ 9.00
11-1
6817208G70GY8
ref: 11-1
EMBLEM,125L,L
€ 11.50
11-2
6817208G70BJB
ref: 11-2
EMBLEM,125L,L
€ 9.00
12-1
6813121H00019
ref: 12-1
EMBLEM,SUZUKI
6813121H00019
€ 11.00
12-2
6813121H0030H
ref: 12-2
EMBLEM,SUZUKI
€ 7.00
