CRANKCASE COVER
DR650SE 2003 (K3) USA (E03)
Crankcase cover diagram DR650SE 2003 (K3) USA (E03)
CRANKCASE COVER DR650SE 2003 (K3) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1
1134032E00
ref: 1
COVER,CLUTCH
€ 192.50
2
1197133210
ref: 2
LENS,OIL LEVEL CHECK
€ 13.50
3
1148232E00
ref: 3
GASKET,CLUTCH COVER
€ 17.00
4
0421109149
ref: 4
PIN
€ 2.00
5-1
0154706457
ref: 5-1
BOLT
€ 2.50
5-2
0910306224
ref: 5-2
BOLT(6X45)
€ 3.00
6-1
0154706357
ref: 6-1
BOLT
€ 2.50
6-2
0910306214
ref: 6-2
BOLT(6X35)
€ 2.50
7-1
0154706307
ref: 7-1
BOLT
€ 2.50
7-2
0910306213
ref: 7-2
BOLT(6X30)
€ 2.50
8-1
0154706257
ref: 8-1
BOLT
€ 2.50
8-2
0910306212
ref: 8-2
BOLT(6X25)
€ 2.50
9
0916806023
ref: 9
GASKET(5.8X13X1.2) (NAS)
€ 2.00
10
0925920019
ref: 10
PLUG
€ 9.50
11
0928017003
ref: 11
O RING(D:3.1,ID:16.8)
€ 2.00
12
1135132E01
ref: 12
COVER,MAGNETO
€ 152.00
13
1148332E00
ref: 13
GASKET,MAGNETO COVER
€ 14.00
14
0421109149
ref: 14
PIN
€ 2.00
15-1
0154706307
ref: 15-1
BOLT
€ 2.50
15-2
0910306213
ref: 15-2
BOLT(6X30)
€ 2.50
16-1
0924814005
ref: 16-1
PLUG,14X12
€ 5.00
16-2
0924814011
ref: 16-2
09248-14005
PLUG
€ 5.00
17
0916814002
ref: 17
09168-14004
GASKET(13.8X18.8X4.8) (NAS)
€ 2.50
18
092593601620H
ref: 18
PLUG(SILVER)
€ 10.50
19
0928033004
ref: 19
O RING(D:3.1,ID:32.7)
€ 2.50
20
1136132E00
ref: 20
COVER,ENGINE SPROCKET
€ 46.50
21-1
0154706357
ref: 21-1
BOLT
€ 2.50
21-2
0910306214
ref: 21-2
BOLT(6X35)
€ 2.50
22
1137112D30
ref: 22
COVER,GEAR SHIFT
€ 41.50
23
1148512D01
ref: 23
GASKET,GEAR SHIFT COVER (NAS)
€ 4.50
24
0421109149
ref: 24
PIN
€ 2.00
25
0154706353
ref: 25
01547-0635B
BOLT
€ 3.00
26
0154706303
ref: 26
01547-0630B
BOLT,G/S SWITC
€ 3.00
27
0154706203
ref: 27
01547-0620B
SCREW
€ 2.50
28
0926212001
ref: 28
BEARING(12X28X8)
€ 15.00
29
0833141286
ref: 29
08331-4128A
CIRCLIP
€ 3.50
