FRAME COVER (MODEL Z)

GS125ES 1983 (D) (E01 E02 E04 E06 E15 E18 E24 E30 E34 E39)

Frame cover (model z) diagram GS125ES 1983 (D) (E01 E02 E04 E06 E15 E18 E24 E30 E34 E39)

FRAME COVER (MODEL Z) GS125ES 1983 (D) (E01 E02 E04 E06 E15 E18 E24 E30 E34 E39)

FRAME COVER (MODEL Z) GS125ES 1983 (D) (E01 E02 E04 E06 E15 E18 E24 E30 E34 E39)

prices are in EUR

ref

part #

description

quantity

1

471110535007P
ref: 1

COVER, FRAME RH (RED)

€ 62.50

2

681310536060D
ref: 2

EMBLEM

€ 5.00

3

6813105350742
ref: 3
GS125Z E1,E2

EMBLEM (SILVER)

€ 7.50

4

681310537060D
ref: 4
GS125EZ E17

EMBLEM

€ 7.50

5-1

4711105350019
ref: 5-1

COVER, FRAME RH (BLACK)

€ 50.00

5-2

471110535004Y
ref: 5-2

COVER, FRAME RH (BLUE)

€ 50.00

6

681310536069P
ref: 6

EMBLEM

€ 5.00

7

681310535074Z
ref: 7
GS125Z E1,E2

EMBLEM (SILVER)

€ 0.00

8

681310537069P
ref: 8
GS125EZ E17

EMBLEM

€ 0.00

9

472110535007P
ref: 9

COVER, FRAME LH (RED)

€ 62.50

10

681310536060D
ref: 10

EMBLEM

€ 5.00

11

6813105350742
ref: 11
GS125Z E1,E2

EMBLEM (SILVER)

€ 7.50

12

681310537060D
ref: 12
GS125EZ E17

EMBLEM

€ 7.50

13-1

4721105350019
ref: 13-1

COVER, FRAME LH (BLACK)

€ 55.50

13-2

472110535004Y
ref: 13-2

COVER, FRAME LH (BLUE)

€ 55.50

14

681310536069P
ref: 14

EMBLEM

€ 5.00

15

6813105350742
ref: 15
GS125Z E1,E2

EMBLEM (SILVER)

€ 7.50

16

681310537069P
ref: 16
GS125EZ E17

EMBLEM

€ 0.00

17

0932008018
ref: 17

CUSHION

€ 4.00

18

0932908003
ref: 18

CUSHION

€ 3.50

19

0932003004
ref: 19

CUSHION

€ 2.00

20

0932005006
ref: 20

CUSHION

€ 4.00
