CHAIN CASE - SHOCK ABSORBER

GS125ES 1990 (L) AUSTRALIA (E24)

Chain case - shock absorber diagram GS125ES 1990 (L) AUSTRALIA (E24)

CHAIN CASE - SHOCK ABSORBER GS125ES 1990 (L) AUSTRALIA (E24)
CHAIN CASE - SHOCK ABSORBER GS125ES 1990 (L) AUSTRALIA (E24)
CHAIN CASE - SHOCK ABSORBER GS125ES 1990 (L) AUSTRALIA (E24)
prices are in EUR
ref
part #
description
quantity
1
6131113000291
ref: 1
CASE, CHAIN (BLACK)
€ 27.50
2
0910006011
ref: 2
BOLT(6X8)
0910006011
€ 2.50
3
0916906010
ref: 3
WASHER
0916906010
€ 3.00
4-1
0110706125
ref: 4-1
MODEL Z/D/F/K
BOLT
€ 2.00
4-2
0113406125
ref: 4-2
MODEL L/M
BOLT ,6X12
€ 1.50
4-3
0157006123
ref: 4-3
MODEL R
BOLT
0157006123
€ 1.50
5
0832121064
ref: 5
MODEL Z/D/F/K
WASHER,LOCK
0832121064
€ 2.00
6
6131643000
ref: 6
NUT,CHAIN CASE RR
6131643000
€ 3.00
7
0932008013
ref: 7
CUSHION
0932008013
€ 4.00
8-1
6210005320
ref: 8-1
GS125ESZ/EZ
ABSORBER ASSY, REAR SHOCK (ORANGE)
€ 182.50
8-2
6210005310
ref: 8-2
GS125Z
ABSORBER ASSY, REAR SHOCK
€ 0.00
8-3
6210005350
ref: 8-3
MODEL D/F/K/L/M/R
ABSORBER ASSY,RR SHOCK
€ 140.00
9-1
0916010001
ref: 9-1
MODEL Z/D/F/K/L/M
WASHER
0916010001
€ 2.00
9-2
0916010059
ref: 9-2
MODEL R
WASHER
0916010059
€ 2.50
10-1
0916010001
ref: 10-1
MODEL D/F/K/L/M
WASHER
0916010001
€ 2.00
10-2
0916010059
ref: 10-2
MODEL R
WASHER
0916010059
€ 2.50
11-1
0916012017
ref: 11-1
MODEL Z/D/F
WASHER(12.1X30X2.3)
0916012017
€ 2.50
11-2
0832221128
ref: 11-2
MODEL K/L/M
WASHER
0832221128
€ 2.00
11-3
0832201127
ref: 11-3
MODEL R
WASHER
0832201127
€ 2.00
12-1
0916010001
ref: 12-1
MODEL Z/D/F/K/L/M
WASHER
0916010001
€ 2.00
12-2
0916010059
ref: 12-2
MODEL R
WASHER
0916010059
€ 2.50
13
0831310107
ref: 13
NUT
0831310107
€ 2.50
