FRONT FORK

ref

part #

description

quantity

1

5110344700
ref: 1

DAMPER ASSEMBLY,RIGHT

€ 133.00

2

5110444700
ref: 2

DAMPER ASSEMBLY,LEFT

€ 143.00

3

5113044700
ref: 3

TUBE,FORK,OUTER,RIGHT

€ 91.00

4

5114044700
ref: 4

TUBE,FORK,LEFT,OUTER

€ 97.00

5

5119548000
ref: 5

PIECE,OIL LOCK

€ 8.50

6

5114748130
ref: 6

BOLT(8X27)

€ 3.50

7

5114831030
ref: 7
51148-36011

GASKET (NAS)

€ 4.00

8

5115211420
ref: 8

BUSH,GUIDE

€ 16.50

9

5116844030
ref: 9

SPACER,OIL SEAL

€ 4.50

10

5115337310
ref: 10
51153-02B00

OIL SEAL,FRONT FORK

€ 15.00

11

5115633130
ref: 11
51156-02B00

CIRCLIP,FORK OIL SEAL

€ 4.50

12

5157137310
ref: 12

DUST SEAL

€ 22.00

13

5113231030
ref: 13

HOLDER,AXLE

€ 31.50

14

0832221088
ref: 14
08322-01087

WASHER

€ 2.00

15

0832121088
ref: 15
08321-01087

LOCK WASHER

€ 2.00

16

0914008005
ref: 16
09140-08017

NUT (8MM)

€ 1.50

17

0110706088
ref: 17
09100-06157

BOLT

€ 2.50

18

5118331030
ref: 18

GASKET,DRAIN,PLUG (NAS)

€ 4.00

19

5117736030
ref: 19

SPRING,REBOUND

€ 4.50

20

5114611400
ref: 20

CYLINDER,FRONT FORK

€ 43.00

21

5119633130
ref: 21

RING,PISTON

€ 7.50

22

5111044500
ref: 22

TUBE,FORK,INNER

€ 146.00

23

5112111420
ref: 23

BUSH

€ 16.50

24

5117144301
ref: 24

SPRING

€ 0.00

25

5118133131
ref: 25

O RING

€ 5.00

26

5117548500
ref: 26

SEAT,SPRING

€ 9.00

27

5116948500
ref: 27

RING,STOPPER

€ 2.00

28

5118944301
ref: 28
51189-44031

CAP,FRONT FORK

€ 7.00

all assemblies
