REAR BRAKE

GS550E 1981 (X) (E01 E02 E04 E18 E21 E22 E24 E25 E26 E30 E34)

Rear brake diagram GS550E 1981 (X) (E01 E02 E04 E18 E21 E22 E24 E25 E26 E30 E34)

REAR BRAKE GS550E 1981 (X) (E01 E02 E04 E18 E21 E22 E24 E25 E26 E30 E34)
REAR BRAKE GS550E 1981 (X) (E01 E02 E04 E18 E21 E22 E24 E25 E26 E30 E34)
REAR BRAKE GS550E 1981 (X) (E01 E02 E04 E18 E21 E22 E24 E25 E26 E30 E34)
prices are in EUR
ref
part #
description
quantity
1
4311034500
ref: 1
PEDAL,BRAKE
4311034500
€ 47.00
2
4312034500
ref: 2
GS550EX
ARM,BRAKE PEDAL
€ 38.00
3
0920006029
ref: 3
GS550EX
PIN
0920006029
€ 1.50
4
0832221068
ref: 4
GS550EX
WASHER
0832221068
€ 2.00
5
0411120158
ref: 5
GS550EX
PIN
0411120158
€ 1.50
6
4312034510
ref: 6
GS550X:E1, E2, E22,
ARM,BRAKE PEDAL
€ 0.00
7
4330034510
ref: 7
GS550X:E1, E2, E22,
ROD, REAR BRAKE
€ 15.50
8
0920006013
ref: 8
GS550X:E1, E2, E22,
PIN(L:13.5)
0920006013
€ 2.00
9
0832221068
ref: 9
GS550X:E1, E2, E22,
WASHER
0832221068
€ 2.00
10
0411120208
ref: 10
GS550X:E1, E2, E22,
PIN 20X20
0411120208
€ 1.50
11
0832221068
ref: 11
GS550X:E1, E2, E22,
WASHER
0832221068
€ 2.00
12
0944009004
ref: 12
GS550X:E1, E2, E22,
SPRING
0944009004
€ 2.00
13
0920913003
ref: 13
GS550X:E1, E2, E22,
PIN
0920913003
€ 3.50
14
0915006001
ref: 14
GS550X:E1, E2, E22,
NUT
0915006001
€ 3.50
15
0110708258
ref: 15
BOLT
0110708258
€ 2.50
16
0832121088
ref: 16
LOCK WASHER
0832121088
€ 2.00
17
0944314013
ref: 17
GS550EX
SPRING
0944314013
€ 21.50
18
0944314015
ref: 18
GS550X:E1, E2, E22,
SPRING
0944314015
€ 3.00
19
0110706208
ref: 19
BOLT
0110706208
€ 2.00
20
0831011068
ref: 20
NUT
0831011068
€ 2.50
