CLUTCH RELEASE

GS550L 1979 (N) USA (E03)

Clutch release diagram GS550L 1979 (N) USA (E03)

CLUTCH RELEASE GS550L 1979 (N) USA (E03)

CLUTCH RELEASE GS550L 1979 (N) USA (E03)

prices are in EUR

ref

part #

description

quantity

2

0928506011
ref: 2

SEAL,OIL(6X34X10)

€ 9.50

3

2311744000
ref: 3

RETAINER,CL PUSH ROD OIL SEAL

€ 17.00

4

0150006127
ref: 4

BOLT

€ 2.00

5

2320030002
ref: 5

SCREW ASSY,CLUTCH RELEASE

€ 80.50

6

0913406010
ref: 6

SCREW(6X25)

€ 3.00

7

0831000067
ref: 7

NUT

€ 2.50

8

0211206127
ref: 8

SCREW

€ 2.00

9

2322207000
ref: 9

PIECE,RELEASE ARM END

€ 5.00

10

0944308001
ref: 10

SPRING

€ 3.00
