GEAR SHIFTING

ref

part #

description

quantity

1

2521144001
ref: 1

FORK,GEAR SHIFT NO.1

€ 70.00

2

2522144001
ref: 2

FORK,GEAR SHIFT NO.2

€ 74.50

3

2523144000
ref: 3

FORK,GEAR SHIFT NO.2

€ 74.50

4

2541118900
ref: 4

SHAFT,GEAR SHIFT FORK

€ 14.50

5

0214206107
ref: 5

SCREW

€ 2.00

6

2531147001
ref: 6

CAM,GEAR SHIFT

€ 68.50

7

0926104001
ref: 7

PIN(4X18.5)

€ 1.50

8

0920904013
ref: 8

PIN

€ 5.00

9

2532244000
ref: 9

RETAINER,GEAR SHIFT CAM DR PIN

€ 2.50

10

0211206167
ref: 10

SCREW

€ 2.50

11

2534133300
ref: 11

GUIDE,GEAR SHIFT CAM

€ 6.00

12

0911106054
ref: 12

BOLT(6X14.6)

€ 1.50

13

0150006127
ref: 13

BOLT

€ 2.00

14

0926340001
ref: 14

BEARING(40X47X12)

€ 21.00

15

2535044000
ref: 15

STOPPER,GEAR SHIFT CAM NO.1

€ 10.50

17

2535130010
ref: 17

STOPPER,GEAR SHIFT CAM NO.2

€ 6.50

18

2535430000
ref: 18

HOLDER,GEAR SHIFT CAM STOP SPR

€ 6.50

19

0944006014
ref: 19

SPRING

€ 1.50

20

0916814004
ref: 20

GASKET(14X19.2X2) (NAS)

€ 2.50

22

0833131126
ref: 22

CIRCLIP,12 MM

€ 2.00

23

0916012090
ref: 23

WASHER (12.5X26X1.6)

€ 2.00

24

0944307013
ref: 24

SPRING

€ 2.50

25

0944426013
ref: 25

SPRING

€ 3.50

26

0918012068
ref: 26

SPACER(12X20X15.3)

€ 3.00

27

2567101011
ref: 27

STOPPER,GEAR SHIFT ARM

€ 3.00

28

0832101087
ref: 28

WASHER,LOCK

€ 2.00

29

0928512006
ref: 29

SEAL,OIL (12X22X9)

€ 7.00

30

2552047000
ref: 30

ARM,GEAR SHIFT LINK

€ 53.50

31

0150006207
ref: 31

BOLT

€ 2.00

32

2552547020
ref: 32

ROD,GEAR SHIFT LINK

€ 9.00

33

0831000067
ref: 33

NUT

€ 2.50

34

0914006011
ref: 34

NUT

€ 1.50

36

2565216500
ref: 36

RUBBER,GEAR SHIFT PEDAL

€ 4.00

37

0916012011
ref: 37

WASHER(12.5X20X1)

€ 1.50

38

0833131126
ref: 38

CIRCLIP,12 MM

€ 2.00

39

3772045100
ref: 39

TERMINAL BASE ASSY,GEAR SHIFT

€ 92.50

40

0928026005
ref: 40

O RING(D:2.4,ID:26.2)

€ 2.50

41

0211205207
ref: 41

SCREW

€ 3.00

42

0832101057
ref: 42

WASHER,LOCK

€ 2.00

43

0832201057
ref: 43

WASHER

€ 2.50

44

0920905011
ref: 44

PIN(5X15.5)

€ 2.00

45

0944004010
ref: 45

SPRING

€ 1.50
