RIGHT HANDLE SWITCH (MODEL Z)

GS650GL 1982 (Z) USA (E03)

Right handle switch (model z) diagram GS650GL 1982 (Z) USA (E03)

RIGHT HANDLE SWITCH (MODEL Z) GS650GL 1982 (Z) USA (E03)

RIGHT HANDLE SWITCH (MODEL Z) GS650GL 1982 (Z) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

5711044011
ref: 1
57110-49510

GRIP,THROTTLE

€ 33.00

2-1

3720049231
ref: 2-1
37200-49232

SWITCH ASSEMBLY,HANDLE,RIGHT

€ 121.00

2-2

3720049211
ref: 2-2
37200-49212

SWITCH ASSEMBLY,HANDLE,RIGHT

€ 164.50

3

3759149210
ref: 3
09125-05102

SCREW

€ 2.50

4

5721549100
ref: 4

CAP,GRIP END

€ 3.50

5

5742049101
ref: 5

LEVER,BRAKE

€ 36.50

6

5743118621
ref: 6

BOLT

€ 8.00

7

0831921068
ref: 7
08319-2106A

NUT 6MM

€ 2.00

8

5746049300
ref: 8
57460-45500

SWITCH ASSEMBLY

€ 40.00

9

5746518601
ref: 9

CONTACT,SWITCH

€ 4.50

10

5748133010
ref: 10

COVER,FR BK TERMINAL BASE

€ 19.50

11

0912503105
ref: 11
09125-03105-XC0

SCREW

€ 2.50

12

0940712402
ref: 12

CLAMP(L:120)

€ 3.00
