WIRING HARNESS (GSF1250SK7/SK8/SK9)

ref

part #

description

quantity

1

3661018H90
ref: 1

HARNESS,WIRING NO.1

€ 524.50

2-1

0948110501
ref: 2-1

FUSE(10A)

€ 3.00

2-2

0948115501
ref: 2-2

FUSE(15A)

€ 1.00

3

3662038G00
ref: 3

HARNESS,WIRING NO.2

€ 122.50

4

3685918H00
ref: 4

WIRE,INJECTOR LEAD

€ 109.00

5-1

0940406429
ref: 5-1

CLAMP(L:45)

€ 2.50

5-2

0940406433
ref: 5-2

CLAMP(L:80)

€ 3.00

6-1

0940711401
ref: 6-1

CLAMP(L:95)

€ 2.50

6-2

0940714403
ref: 6-2

CLAMP(L:125)

€ 2.50

6-3

0940718402
ref: 6-3

CLAMP(L:165)

€ 2.50

6-4

0940725401
ref: 6-4

CLAMP(L:235)

€ 4.00

7

0940714407
ref: 7

CLAMP(L:145)

€ 4.00

8

0940703401
ref: 8

CLAMP(L:33)

€ 3.50

9

015500612A
ref: 9

BOLT

€ 2.50

10

3685118H00
ref: 10

WIRE,OIL PRESSURE SWITCH LEAD

€ 14.50

11

3700049830
ref: 11
37000-49831

LOCK SET

€ 295.00

12

3710049G00
ref: 12
37100-49G01

LOCK ASSY,STEE

€ 165.00

13

0913908016
ref: 13

BOLT(8X20)

€ 3.50

14

3774024A00
ref: 14

SWITCH ASSY,STOP LAMP

€ 20.50

15

0944306054
ref: 15

SPRING

€ 2.50

16

3784025D00
ref: 16

SWITCH ASSY,SIDE STAND

€ 63.50

17

071200620B
ref: 17

BOLT

€ 3.50

18

3850018H00
ref: 18

HORN ASSY

€ 73.00

19

015500612B
ref: 19

BOLT

€ 2.50

20

3874024X50
ref: 20

RELAY ASSY

€ 37.50

21

3874024X50
ref: 21

RELAY ASSY

€ 37.50

22

3714633E00
ref: 22

KEY,BLANK

€ 13.00

23

6313110F00
ref: 23

TAPE,RR FENDER

€ 6.00

24

3365238A10
ref: 24
33652-07D00

PROTECTOR(20X90)X2

€ 4.50
