CAM CHAIN (MODEL D)

GSX250ES 1982 (Z) GENERAL EXPORT (E01)

Cam chain (model d) diagram GSX250ES 1982 (Z) GENERAL EXPORT (E01)

CAM CHAIN (MODEL D) GSX250ES 1982 (Z) GENERAL EXPORT (E01)
CAM CHAIN (MODEL D) GSX250ES 1982 (Z) GENERAL EXPORT (E01)
CAM CHAIN (MODEL D) GSX250ES 1982 (Z) GENERAL EXPORT (E01)
prices are in EUR
ref
part #
description
quantity
1
1276011400
ref: 1
CHAIN,CAMSHAFT DRIVE
€ 115.50
2
1277111401
ref: 2
GUIDE,CAM CHAIN NO.1
1277111401
€ 37.50
3
1278247040
ref: 3
GUIDE,CAM CHAIN NO.3
1278247040
€ 89.50
4
0211205128
ref: 4
SCREW
€ 2.50
5
1281011400
ref: 5
TENSIONER,CAM CHAIN
1281011400
€ 62.50
6
1281444101
ref: 6
CUSHION,CAM CHAIN TENSIONER
1281444101
€ 8.50
7
1283047011
ref: 7
ADJUSTER ASSEMBLY,TENSIONER
1283047011
€ 167.00
8
1283347001
ref: 8
ROD,PUSH
1283347001
€ 25.00
9
0944012017
ref: 9
SPRING
0944012017
€ 2.50
10
1283845010
ref: 10
SCREW,TENSIONER ADJUST
€ 6.00
11
0928021013
ref: 11
O RING(D:2.4,ID:20.8)
0928021013
€ 4.50
12
0928006005
ref: 12
O RING(D:1.9,ID:5.7)
0928006005
€ 2.50
13
0928410006
ref: 13
SEAL,OIL(10X16X4)
0928410006
€ 4.00
14
0832211085
ref: 14
WASHER,8.5X16X
€ 1.50
15
0831011085
ref: 15
NUT
€ 1.50
16
0831616065
ref: 16
NUT
€ 2.50
17
1283747000
ref: 17
GASKET,TENSIONER ADJUSTER (MCA)
1283747000
€ 7.50
18
0912806022
ref: 18
SCREW
€ 2.50
