COWLING BODY (MODEL X)

GSX750F 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) P37

Cowling body (model x) diagram GSX750F 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) P37

COWLING BODY (MODEL X) GSX750F 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) P37
COWLING BODY (MODEL X) GSX750F 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) P37
COWLING BODY (MODEL X) GSX750F 1998 (W) (E02 E04 E17 E18 E22 E24 E25 E34) P37
prices are in EUR
ref
part #
description
quantity
1
9440308F3033J
ref: 1
COWLING ASSY,SIDE,R
€ 461.00
1
9440308F30Y4M
ref: 1
COWLING,SIDE,R
€ 510.00
1
9440308F30Y7H
ref: 1
COWLING ASSY,SIDE,R
€ 501.50
2
9440408F3033J
ref: 2
COWLING ASSY,SIDE,L
€ 496.50
2
9440408F30Y4M
ref: 2
COWL ASSY, SIDE LH (MAROON)
9440408F30Y4M
€ 493.50
2
9440408F30Y7H
ref: 2
COWLING ASSY,SIDE,L
€ 525.00
3
6868108F10
ref: 3
EMBLEM,COWLING SIDE,GSXF,R
6868108F10
€ 42.00
4
6869108F10
ref: 4
EMBLEM,COWLING SIDE,GSXF,L
6869108F10
€ 39.50
5
9463144110
ref: 5
MOLD,COWLING
9463144110
€ 18.00
6
9443908F00
ref: 6
SHIELD,COWLING COVER,R
9443908F00
€ 57.00
7
9444908F00
ref: 7
SHIELD,COWLING COVER,L
9444908F00
€ 57.00
8
9441008F0033J
ref: 8
PANEL,COWLING CTR UPR
9441008F0033J
€ 23.50
8
9441008F00Y4M
ref: 8
PANEL,COWLING CTR UPR
9441008F00Y4M
€ 52.00
8
9441008F00Y7H
ref: 8
PANEL COMP,COWLING,CENTER
€ 58.00
9
6818505C1020H
ref: 9
EMBLEM,SUZUKI(SILVER)
6818505C1020H
€ 13.50
10
9441308F00
ref: 10
CUSHION,CTR PANEL UPR
9441308F00
€ 2.50
11
9443508F0033J
ref: 11
LID,OIL
9443508F0033J
€ 620.50
11
9443508F00Y4M
ref: 11
LID,OIL
€ 22.00
11
9443508F00Y7H
ref: 11
LID,OIL
€ 22.00
12
0913906030
ref: 12
SCREW(6X16)
0913906030
€ 3.50
13
9461108F00
ref: 13
WINDSCREEN
9461108F00
€ 243.00
14
0913905025
ref: 14
SCREW(5X14)
0913905025
€ 2.00
15
0832201053
ref: 15
WASHER
0832201053
€ 2.50
16
0915905019
ref: 16
NUT
0915905019
€ 5.50
17
09409083085ES
ref: 17
CLIP(BLACK)
09409083085ES
€ 2.00
18
9442108F00
ref: 18
PANEL,METER
9442108F00
€ 111.00
19
9441208F0033J
ref: 19
PANEL,COWLING CTR LWR
€ 18.00
19
9441208F00Y4M
ref: 19
PANEL,COWLING CTR LWR
9441208F00Y4M
€ 49.00
19
9441208F00Y7H
ref: 19
PANEL,COWLING CTR LWR
9441208F00Y7H
€ 49.00
20
9441408F00
ref: 20
CUSHION,CENTER PANEL,LOWER
9441408F00
€ 2.50
21
9446108F0033J
ref: 21
PANEL,COWLING,INNER,RIGHT
€ 45.50
21
9446108F00Y4M
ref: 21
PANEL,COWLING,INNER,RIGHT
€ 82.50
21
9446108F00Y7H
ref: 21
PANEL,COWLING,INNER,RIGHT
€ 90.00
22
9446208F0033J
ref: 22
PANEL,COWLING,INNER,LEFT
9446208F0033J
€ 64.50
22
9446208F00Y4M
ref: 22
PANEL,COWLING,INNER,LEFT
€ 82.50
22
9446208F00Y7H
ref: 22
PANEL,COWLING,INNER,LEFT
€ 89.00
23
9445120C01
ref: 23
PLATE,AIR GUIDE
9445120C01
€ 45.00
23
9445120C11
ref: 23
E18
PLATE,AIR GUIDE
€ 57.00
24
0940718402
ref: 24
E18
CLAMP(L:165)
0940718402
€ 2.50
24
0940725401
ref: 24
E18
CLAMP(L:235)
0940725401
€ 4.00
