FRAME COVER (MODEL X)

ref

part #

description

quantity

1

4711008F3033J
ref: 1

COVER,FRAME,R(BLACK)

€ 119.00

1

4711008F30Y4M
ref: 1

COVER,FRAME,R(MAROON)

€ 171.00

1

4711008F30Y7H
ref: 1

COVER,FRAME,R(BLUE)

€ 119.00

2

4721008F3033J
ref: 2

COVER COMP,FRAME,LEFT

€ 193.50

2

4721008F30Y4M
ref: 2

COVER,FRAME,L(MAROON)

€ 181.50

2

4721008F30Y7H
ref: 2

COVER,FRAME,L(BLUE)

€ 181.50

3

6813108F30M4Y
ref: 3
FOR 33J

EMBLEM,FRAME COVER

€ 11.00

3

6813108F30M4Z
ref: 3
FOR Y4M

EMBLEM,FRAME COVER

€ 14.50

3

6813108F30M5A
ref: 3
FOR Y7H

EMBLEM,FRAME COVER

€ 15.00

4

0913606105
ref: 4

SCREW(6X20)

€ 2.00

5

0918006286
ref: 5

SPACER(6.5X10X9.4)

€ 2.50

6

0932010045
ref: 6

CUSHION

€ 3.50

7

0932008028
ref: 7

CUSHION

€ 2.50

8

0932008018
ref: 8

CUSHION

€ 4.00

9

0324115163
ref: 9

SCREW

€ 2.00

10

0324115123
ref: 10

SCREW

€ 2.50

11

0914805038
ref: 11

NUT

€ 2.50

12

4489424A00
ref: 12

CUSHION

€ 1.50

13

4716108F00
ref: 13

CUSHION,FRAME COVER

€ 6.00

all assemblies
