FRAME COVER (MODEL K2)
GSX750F KATANA 1998 (W) USA (E03)
Frame cover (model k2) diagram GSX750F KATANA 1998 (W) USA (E03)
FRAME COVER (MODEL K2) GSX750F KATANA 1998 (W) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
4711008F5019A
ref: 1-1
COVER,FRAME,R(RED)
€ 119.00
1-2
4711008F50YFX
ref: 1-2
COVER,FRAME,R(BLACK)
€ 171.00
2-1
4721008F5019A
ref: 2-1
COVER,FRAME,L(RED)
€ 31.50
2-2
4721008F50YFX
ref: 2-2
COVER,FRAME(BL
€ 31.50
3-1
6813108F50HR3
ref: 3-1
EMBLEM,FRAME COVER
€ 8.50
3-2
6813108F50EG1
ref: 3-2
EMBLEM,FRAME COVER
€ 11.50
4
0913606105
ref: 4
SCREW(6X20)
€ 2.00
5
0918006286
ref: 5
SPACER(6.5X10X9.4)
€ 2.50
6
0932010045
ref: 6
CUSHION
€ 3.50
7
0932008028
ref: 7
CUSHION
€ 2.50
8
0932008018
ref: 8
CUSHION
€ 4.00
9
0324115163
ref: 9
03241-1516A
SCREW
€ 2.00
10
0324115123
ref: 10
03241-1512B
SCREW
€ 2.50
11
0914805038
ref: 11
NUT
€ 2.50
12
4489424A00
ref: 12
CUSHION
€ 1.50
13
4716108F00
ref: 13
CUSHION,FRAME COVER
€ 6.00
