GENERATOR

GSXR1000 2006 (K6) USA (E03)

Generator diagram GSXR1000 2006 (K6) USA (E03)

GENERATOR GSXR1000 2006 (K6) USA (E03)

GENERATOR GSXR1000 2006 (K6) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

3140141G00
ref: 1

STARTER ASSY

€ 473.00

2

3140241G00
ref: 2
31402-41G10

ROTOR ASSY

€ 189.50

3

3237133E00
ref: 3

CLAMP,MAGNETO LEAD

€ 3.50

4

0910312005
ref: 4

BOLT(12X23)

€ 5.50

5

0713006123
ref: 5
07130-0612A

BOLT,STRANGER

€ 2.50

6

0910606089
ref: 6

BOLT(6X30)

€ 4.00
