CYLINDER HEAD COVER

GSXR600X 2005 (K5) USA (E03)

Cylinder head cover diagram GSXR600X 2005 (K5) USA (E03)

CYLINDER HEAD COVER GSXR600X 2005 (K5) USA (E03)

CYLINDER HEAD COVER GSXR600X 2005 (K5) USA (E03)

prices are in EUR

ref

part #

description

quantity

1

1117129G00
ref: 1

COVER,CYLINDER HEAD

€ 297.00

2

1117329G00
ref: 2

GASKET,CYL HEAD COVER NO.1 (NAS)

€ 37.00

3

1117829G00
ref: 3

GASKET,CYL HEAD COVER NO.2 (NAS)

€ 8.00

4

0910607009
ref: 4

BOLT(7X17.5)

€ 4.50

5

0916111008
ref: 5

WASHER(10.6X25.5X2.3)

€ 4.50
