RADIATOR
GSXR600X 2005 (K5) USA (E03)
Radiator diagram GSXR600X 2005 (K5) USA (E03)
RADIATOR GSXR600X 2005 (K5) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
1771029G00
ref: 1-1
RADIATOR ASSY,WATER
€ 772.50
1-1
1771029G00
ref: 1-1
RADIATOR ASSY,WATER
€ 772.50
1-2
1771030G00
ref: 1-2
RADIATOR ASSY,WATER
€ 921.00
2-1
1773012C20
ref: 2-1
17730-08J00
CAP COMP,RADIATOR
€ 40.00
2-1
1773012C20
ref: 2-1
17730-08J00
CAP COMP,RADIATOR
€ 40.00
2-2
1773014G00
ref: 2-2
CAP,RADIATOR(1.1)
€ 36.00
3
0911806097
ref: 3
BOLT(6X25)
€ 2.50
4
0918006290
ref: 4
SPACER(6.5X10X12)
€ 2.50
5
0932010051
ref: 5
CUSHION
€ 3.50
6-1
1775029G00
ref: 6-1
BRACKET,RADIATOR
€ 11.50
6-1
1775029G00
ref: 6-1
BRACKET,RADIATOR
€ 11.50
6-2
1775030G00
ref: 6-2
BRACKET,RADIATOR
€ 8.50
7
0155006123
ref: 7
01550-0612A
BOLT
€ 2.50
8-1
1780029G00
ref: 8-1
FAN ASSY,RADIATOR
€ 511.50
8-1
1780029G00
ref: 8-1
FAN ASSY,RADIATOR
€ 511.50
8-2
1780030G00
ref: 8-2
FAN ASSY,RADIATOR
€ 475.00
9-1
1771140F00
ref: 9-1
BOLT,FAN ASSY
€ 3.50
9-1
1771140F00
ref: 9-1
BOLT,FAN ASSY
€ 3.50
9-2
1771114G00
ref: 9-2
BOLT,FAN ASSY
€ 2.50
10-1
1771240F00
ref: 10-1
NUT,FAN ASSY
€ 3.50
10-1
1771240F00
ref: 10-1
NUT,FAN ASSY
€ 3.50
10-2
1780214F00
ref: 10-2
NUT,RADIATOR FAN
€ 3.00
