CRANKSHAFT

ref

part #

description

quantity

1-1

1211010202
ref: 1-1

PISTON

€ 40.50

1-2

1211010202050
ref: 1-2
OS:0.5

PISTON

€ 70.50

1-3

1211010202100
ref: 1-3
OS:1.0

PISTON

€ 43.00

2-1

1214028630
ref: 2-1

RING SET,PISTON

€ 52.00

2-2

1214028630050
ref: 2-2
OS:0.5

RING SET,PISTON(OS:0.50)

€ 50.50

2-3

1214028630100
ref: 2-3
OS:1.0

RING SET,PISTON (OS:1.0)

€ 52.00

3

1215107000
ref: 3

PIN,PISTON 14MM

€ 10.00

4

0938114001
ref: 4

RING,SNAP 14MM

€ 1.50

5

0926314006
ref: 5

BEARING

€ 10.00

6

1220010300
ref: 6

CRANKSHAFT ASSY

€ 0.00

7

1216112002
ref: 7

CONNECTING ROD

€ 54.50

8

1221110300
ref: 8

PIN,CRANK

€ 25.00

9

0916019001
ref: 9
19*32*1

WASHER(19X32X1)

€ 3.50

10

0926319009
ref: 10

BEARING(19X25X16)

€ 15.00

11

1222110300
ref: 11

CRANKSHAFT, RH

€ 0.00

12

1223110300
ref: 12

WEB, CRANK

€ 0.00

13

1224110300
ref: 13

CRANKSHAFT, MIDDLE

€ 0.00

14

1226110300
ref: 14

CRANKSHAFT, LH

€ 0.00

15

0926225036
ref: 15
25*62*17

BEARING(25X62X17)

€ 38.50

16

0821125343
ref: 16

WASHER

€ 0.00

17

0926225034
ref: 17
25*62*17

BEARING

€ 55.00

18

0928930007
ref: 18

SEAL,OIL(30X62X11)

€ 11.00

19

0939062009
ref: 19

C RING

€ 5.00

20

0916020025
ref: 20
20*48*1

WASHER(20X48X1)

€ 2.50

21

2111110200
ref: 21
NT:21

GEAR, PRIMARY DRIVE

€ 0.00

22

2642110300
ref: 22
NT:19

GEAR, TACHOMETER DRIVE NO.1

€ 0.00

23

0916416002
ref: 23

WASHER

€ 3.00

24

0914016002
ref: 24

NUT

€ 4.00

25

0834131059
ref: 25

KEY

€ 3.00
