HEADLAMP (E24)

GZ250 2000 (Y) (E01)

Headlamp (e24) diagram GZ250 2000 (Y) (E01)

prices are in EUR

ref

part #

description

quantity

3510013F00999
ref: 1

HEADLAMP ASSEMBLY

€ 0.00

3515413F00
ref: 2

SPRING

€ 2.00

3511113F00
ref: 3

RIM,HEAD LAMP

€ 67.50

3513113F00
ref: 4

STAY

€ 14.50

3513545900
ref: 5

NUT

€ 2.50

3514513F00
ref: 6

SPRING

€ 2.50

3515113F00
ref: 7

ADJUSTER SCREW

€ 4.00

3515245600
ref: 8

NUT,HEADLAMP ADJUST

€ 3.00

3516113F00
ref: 9

SCREW

€ 3.50

3516513F00
ref: 10

CAP,SCREW

€ 1.50

3517338A00
ref: 11

COVER,SOCKET

€ 12.50

3518113F00
ref: 12

SCREW

€ 3.00

0947112185
ref: 13

BULB(12V60/55W,H4)

€ 8.00

3519213F00
ref: 14

SPACER,HEADLAMP

€ 7.00

0211205207
ref: 15

SCREW

€ 3.00
