FOOTREST

RF900R 1996 (T) (E02 E04 E18 E22 E24 E25 E34 E37 E39)

Footrest diagram RF900R 1996 (T) (E02 E04 E18 E22 E24 E25 E34 E37 E39)

FOOTREST RF900R 1996 (T) (E02 E04 E18 E22 E24 E25 E34 E37 E39)
FOOTREST RF900R 1996 (T) (E02 E04 E18 E22 E24 E25 E34 E37 E39)
FOOTREST RF900R 1996 (T) (E02 E04 E18 E22 E24 E25 E34 E37 E39)
prices are in EUR
ref
part #
description
quantity
1
4351131E00
ref: 1
BAR,FR FOOTREST,R
4351131E00
€ 45.00
2
4352140C00
ref: 2
BAR,FOOTREST,L
4352140C00
€ 37.50
3
4355046E00
ref: 3
RUBBER,FOOTREST
4355046E00
€ 16.50
4
4353446E00
ref: 4
BAR,FR FOOTREST NO.2
4353446E00
€ 21.00
5-1
4353631E00
ref: 5-1
MODEL R/S
BALANCER,FRONT FOOTREST,LOWER
€ 25.50
5-2
4353631E01
ref: 5-2
MODEL T/V/W
BALANCER,FR FOOTREST LWR
4353631E01
€ 25.50
6-1
4357648801
ref: 6-1
MODEL R/S/T/V
SENSOR, RH
€ 0.00
6-2
4357648802
ref: 6-2
MODEL W
SENSOR, RH
€ 0.00
7
0211235303
ref: 7
SCREW
€ 2.50
8
0211235353
ref: 8
SCREW
€ 2.50
9
0920008057
ref: 9
PIN
0920008057
€ 3.00
10-1
0944819020
ref: 10-1
MODEL R/S
SPRING
0944819020
€ 3.50
10-2
0944818022
ref: 10-2
MODEL T/V/W
SPRING
0944818022
€ 3.50
11
0918008149
ref: 11
SPACER(8.1X12X22)
0918008149
€ 7.00
12
0411125158
ref: 12
PIN 20X15
0411125158
€ 1.50
13
4353031E10
ref: 13
HOLDER,FRONT FOOTREST
4353031E10
€ 66.50
14
4354031E00
ref: 14
HOLDER,FR FOOTREST
4354031E00
€ 61.50
15
4357031E10
ref: 15
CUSHION,FR FOOTREST
4357031E10
€ 11.50
16
0831931128
ref: 16
NUT 12MM
0831931128
€ 4.00
17
0831000123
ref: 17
NUT
€ 2.50
18
4321417C01
ref: 18
WASHER,FR FOOTREST
4321417C01
€ 52.50
19
4351121E00
ref: 19
BRACKET,FOOTREST,R
4351121E00
€ 168.00
20
4352121E00
ref: 20
BRACKET,FOOTREST,L
4352121E00
€ 168.00
21
0155008203
ref: 21
BOLT
0155008203
€ 3.00
22
0916408015
ref: 22
WASHER
0916408015
€ 3.00
23
0910608129
ref: 23
BOLT(8X25)
0910608129
€ 5.00
24
0931908025
ref: 24
BUSH
0931908025
€ 13.50
25-1
0916008021
ref: 25-1
MODEL R/S/T/V
WASHER (8.2X24X1.6)
0916008021
€ 2.00
25-2
0916008131
ref: 25-2
MODEL W
WASHER (8.5X24X1.6)
0916008131
€ 2.00
26
3285110D00
ref: 26
PROTECTOR(12X40)
3285110D00
€ 4.50
27
4360031E00
ref: 27
FOOTREST ASSY,PILLION,R
4360031E00
€ 215.00
28
4370031E00
ref: 28
FOOTREST ASSY,PILLION,L
4370031E00
€ 205.00
29
4361040C00
ref: 29
BAR,PILLION FOOTREST,R
4361040C00
€ 49.00
30
4362040C00
ref: 30
BAR,PILLION FOOTREST,L
4362040C00
€ 49.00
31
4355040C11
ref: 31
RUBBER,FOOTREST
4355040C11
€ 16.00
32
0211235163
ref: 32
SCREW
€ 2.50
33
0211235203
ref: 33
SCREW
0211235203
€ 2.50
34
4364240C00
ref: 34
BOLT,PILLION FOOTREST
4364240C00
€ 5.50
35
0944005003
ref: 35
SPRING
0944005003
€ 1.50
36
0611107004
ref: 36
BALL
0611107004
€ 1.50
37-1
0916010031
ref: 37-1
MODEL R/S/T/V
WASHER
0916010031
€ 2.50
37-2
0916010126
ref: 37-2
MODEL W
WASHER(10.5X24X1.6)
0916010126
€ 2.50
38
0833211063
ref: 38
E.RING
0833211063
€ 2.00
39
0910608106
ref: 39
BOLT(8X20)
0910608106
€ 3.00
