TRANSMISSION (MODEL Z)

ref

part #

description

quantity

1

2412014220
ref: 1

SHAFT,COUNTER

€ 152.50

2

2422114220
ref: 2

GEAR,SECOND DRIVE

€ 51.50

3

2423014220
ref: 3

GEAR,THIRD DRIVE

€ 39.50

4

2424014220
ref: 4

GEAR,FOURTH DRIVE

€ 52.00

5

0821125301
ref: 5

WASHER

€ 3.00

6

0938025003
ref: 6

RING,SNAP

€ 3.00

7

0926222006
ref: 7

BEARING

€ 63.50

8

0811360040
ref: 8

BEARING, LH

€ 20.50

9

0821120283
ref: 9

WASHER

€ 2.50

10

2474114210
ref: 10

RETAINER,BEARING

€ 0.00

11

0211206128
ref: 11

SCREW 6X12

€ 2.00

12

2413014220
ref: 12

SHAFT,DRIVE

€ 102.00

13

2431114220
ref: 13

GEAR,FIRST DRIVEN

€ 51.00

14

2432014220
ref: 14

GEAR,SECOND DRIVEN

€ 42.00

15

2433114220
ref: 15

GEAR,THIRD DRIVEN

€ 68.50

16

0821120301
ref: 16

WASHER

€ 3.00

17

0821120363
ref: 17

WASHER

€ 3.50

18

0916728004
ref: 18

WASHER

€ 0.00

19

0938028004
ref: 19

CIRCLIP

€ 1.50

20

0926320018
ref: 20

BEARING(20X24X10).8

€ 14.00

21

0926420002
ref: 21

BEARING

€ 25.50

22

0926228004
ref: 22

BEARING(28X58X16)

€ 33.00

23

0928335023
ref: 23

SEAL,OIL(35X45X6)

€ 9.50

24

2475114211
ref: 24

RETAINER,DRIVESHAFT

€ 0.00

25

0212206128
ref: 25

SCREW

€ 3.00

26

2475214220
ref: 26

PLATE,DRIVESHAFT BEARING

€ 5.50

27

0212206128
ref: 27

SCREW

€ 3.00

28

2626014200
ref: 28

GEAR,KICK STARTER IDLE

€ 41.00

29

0821120281
ref: 29

WASHER,THRUST

€ 2.50

30

0833111209
ref: 30

CIRCLIP

€ 2.50

31

2751114220
ref: 31

SPROCKET,ENGINE (NT:14)

€ 24.50

31

2751114230
ref: 31
OPT

SPROCKET,ENGINE(NT:13)

€ 19.00

31

2751114240
ref: 31
OPT

SPROCKET,ENGINE (NT:15)

€ 21.00

32

0918028003
ref: 32

SPACER(28X35X11.4)

€ 11.50

33

0914028001
ref: 33

NUT

€ 8.00

34

0916728003
ref: 34

WASHER,LOCK

€ 6.50

35

0928028004
ref: 35

O RING(D:1.5,ID:27.7)

€ 7.50

36

2760014252
ref: 36

CHAIN ASSEMBLY,DRIVE

€ 80.00
