CRANKCASE
SV650S 2006 (K6) USA (E03)
Crankcase diagram SV650S 2006 (K6) USA (E03)
CRANKCASE SV650S 2006 (K6) USA (E03)
×
prices are in EUR
ref
part #
description
quantity
1-1
1130120860
ref: 1-1
CRANKCASE SET
€ 1,629.50
1-2
1130120881
ref: 1-2
11301-20883
CRANKCASE SET
€ 2,002.50
2
0920611007
ref: 2
PIN(8.4X11X20)
€ 1.50
3
0928015007
ref: 3
O RING(D:2.4,ID:15.8)
€ 2.00
4
0154706503
ref: 4
01547-0650B
BOLT
€ 3.50
5
0154706507
ref: 5
BOLT
€ 2.50
6
0712008553
ref: 6
BOLT
€ 2.50
7
0712008803
ref: 7
07120-0880B
BOLT
€ 3.00
8
0949328010
ref: 8
JET,AIR(14)
€ 10.50
9
0928004004
ref: 9
O RING(D:1.2,ID:4)
€ 2.00
10
0949328010
ref: 10
JET,AIR(14)
€ 10.50
11
0928004004
ref: 11
O RING(D:1.2,ID:4)
€ 2.00
12
1659106B00
ref: 12
16591-06B01
UNION,OIL STAND
€ 6.00
13
0928012009
ref: 13
O RING(D:1.9,ID:12.6)
€ 2.50
14
1132917G00
ref: 14
JET,OIL GALLERY(3.6)
€ 6.00
15
0924712011
ref: 15
PLUG(12X20)
€ 4.50
16
0916812002
ref: 16
GASKET(12.1X16.2X3.7) (NAS)
€ 2.00
17
1643819F00
ref: 17
PLATE,PISTON COOLING JET
€ 2.50
18
0910606075
ref: 18
BOLT(6X12)
€ 2.50
19
0928004004
ref: 19
O RING(D:1.2,ID:4)
€ 2.00
20
0949326007
ref: 20
JET(13)
€ 13.50
21
0155008123
ref: 21
01550-0812A
BOLT
€ 3.50
22
0916808016
ref: 22
GASKET(8.2X14X1) (NAS)
€ 1.00
23
0924816012
ref: 23
PLUG,16X8
€ 4.50
24
0916816002
ref: 24
GASKET(16X22X2) (NAS)
€ 2.00
25
1132319F00
ref: 25
PLATE,OIL SEPARATOR
€ 3.00
26
0154706123
ref: 26
01547-0612B
BOLT
€ 2.00
27-1
0155006123
ref: 27-1
01550-0612A
BOLT
€ 2.50
27-2
0155006103
ref: 27-2
01550-0610A
BOLT
€ 2.50
28
0916806023
ref: 28
GASKET(5.8X13X1.2) (NAS)
€ 2.00
29-1
0924812004
ref: 29-1
PLUG(L:12)
€ 5.50
29-2
0924712006
ref: 29-2
PLUG(12X10)
€ 2.50
30
0916812017
ref: 30
GASKET(12X17X1) (NAS)
€ 2.00
31
0910310137
ref: 31
BOLT(10X255)
€ 10.00
32
0910310205
ref: 32
BOLT(10X225)
€ 9.50
33
0910312054
ref: 33
BOLT(12X310)
€ 15.00
34
0915910115
ref: 34
NUT
€ 4.00
35
0915912054
ref: 35
NUT
€ 8.00
36
3782033D10
ref: 36
SWITCH ASSY,OIL PRESSURE
€ 29.00
37
3782233D00
ref: 37
BOLT,OIL PRESSURE SWITCH
€ 3.00
