CRANKCASE
T305 TC305 1969 USA (E03)
Crankcase diagram T305 TC305 1969 USA (E03)
CRANKCASE T305 TC305 1969 USA (E03)
×
prices are in EUR
ref
part #
description
quantity
4
0150006553
ref: 4
BOLT
€ 2.00
7
0150006853
ref: 7
BOLT
€ 2.50
9
0150008653
ref: 9
BOLT
€ 3.00
10
0150008703
ref: 10
BOLT
€ 2.50
11
0150008753
ref: 11
BOLT
€ 3.00
12
0421111129
ref: 12
PIN
€ 2.00
13
0832101067
ref: 13
WASHER,LOCK
€ 2.50
14
0832101087
ref: 14
WASHER,LOCK
€ 2.00
15
0832201067
ref: 15
WASHER
€ 2.00
16
0832201087
ref: 16
WASHER
€ 2.00
17
0832201107
ref: 17
WASHER
€ 2.50
18
0832201127
ref: 18
WASHER
€ 2.00
19
0910008023
ref: 19
BOLT 8X100
€ 2.00
23
0915912102
ref: 23
NUT
€ 5.00
24
0916810002
ref: 24
GASKET(10X14X3.6) (NAS)
€ 2.00
25
0916814004
ref: 25
GASKET(14X19.2X2) (NAS)
€ 2.50
26
0918012028
ref: 26
SPACER
€ 11.50
27
0924710001
ref: 27
PLUG
€ 3.00
