Buy Suzuki TA Parts Online


PARTS FOR TA DE LUXE MODEL

TA250 TWIN ACE 1960

Parts for ta de luxe model diagram TA250 TWIN ACE 1960

PARTS FOR TA DE LUXE MODEL TA250 TWIN ACE 1960
PARTS FOR TA DE LUXE MODEL TA250 TWIN ACE 1960
PARTS FOR TA DE LUXE MODEL TA250 TWIN ACE 1960
prices are in EUR
ref
part #
description
quantity
1
TAA4510
ref: 1
DUAL SEAT ASSY.
€ 0.00
2
TAA4512
ref: 2
TENSION SPRING
€ 0.00
3
TAA4517
ref: 3
DUAL SEAT SPRING
€ 0.00
4
SB4593
ref: 4
SET WASHER
€ 2.00
5
TAA4611
ref: 5
SUB CARRIER COMP.
€ 0.00
6
TAA4612
ref: 6
SUB CARRIER UPPER SET BOLT
€ 0.00
7
TAA5511
ref: 7
FRONT TIRE
€ 0.00
8
TAA6299
ref: 8
UPPER DISTANCE COLLAR
€ 0.00
9
TAA6511
ref: 9
REAR TIRE
€ 0.00
10
BG0615
ref: 10
6X15 HEXAGON BOLT
€ 0.00
11
BG0812
ref: 11
8X12 HEXAGON BOLT
€ 2.50
12
WM061
ref: 12
6MM PLANE WASHER
€ 0.00
13
WM081
ref: 13
8MM PLANE WASHER
€ 0.00
14
WS06
ref: 14
6MM SPRING WASHER
€ 2.50
15
WS08
ref: 15
8MM SPRING WASHER
€ 2.00
16
NG061
ref: 16
6MM HEXAGON NUT
€ 2.50
17
NG081
ref: 17
8MM HEXAGON NUT
€ 2.00
