WIRE HARNESS

ref

part #

description

quantity

1

TA7110
ref: 1

WIRE HARNESS ASSY.

€ 0.00

2

SB7131
ref: 2

RUBBER PIPE BUSH

€ 0.00

3

AAL2141
ref: 3

CORD CLIP BUSH

€ 0.00

4

TA7133
ref: 4

RUBBER PIPE BUSH

€ 0.00

5

TA7134
ref: 5

WIRE HARNESS CLIP BAND

€ 2.00

6

SB72101
ref: 6

MAIN SWITCH BODY

€ 0.00

6

SB7210
ref: 6

MAIN SWITCH ASSY.

€ 0.00

7

SB72105
ref: 7
#353

MAIN SWITCH PRESS KEY

€ 0.00

8

SB72106
ref: 8
#515

MAIN SWITCH MASCOT KEY

€ 0.00

9

AAL5600
ref: 9
#535

STOP LAMP SWITCH ASSY.

€ 0.00

10

AAL5631
ref: 10

RUBBER CAP (A)

€ 0.00

11

AAL5632
ref: 11

RUBBER CAP (B)

€ 0.00

12

SB73201
ref: 12

TAIL STOP LAMP BODY COMP.

€ 0.00

12

SB7320
ref: 12

TAIL STOP LAMP ASSY.

€ 0.00

13

SB73202
ref: 13

LENS SET PACKING

€ 0.00

14

SB73203
ref: 14
12V 5W

TAIL LAMP VALVE

€ 2.00

15

SB73204
ref: 15
12V 20W

STOP LAMP VALVE

€ 0.00

16

SB73205
ref: 16

TAIL STOP LAMP LENS

€ 0.00

17

SB73206
ref: 17

BODY RUBBER BUSH

€ 0.00

18

PN0412
ref: 18

4X12 CROSS SCREW

€ 0.00

19

PN0420F
ref: 19

4X20 CROSS SCREW

€ 1.00

20

PN0610
ref: 20

6X10 CROSS SCREW

€ 1.50

21

WM041F
ref: 21

4MM PLANE WASHER

€ 0.00

22

WS06
ref: 22

6MM SPRING WASHER

€ 2.50
