TRANSMISSION

ref

part #

description

quantity

1

TA1431
ref: 1

BEARING KNOCK RING

€ 2.50

2

SB2371
ref: 2

PUSH ROD OIL SEAL

€ 1.50

3

TA2411
ref: 3
TA 11155 12 N.T

COUNTER SHAFT

€ 0.00

3

TA2411A
ref: 3
TA 11156 13 N.T

COUNTER SHAFT

€ 0.00

4

TA2422
ref: 4
19 N.T

SECOND PINION

€ 0.00

5

TA2423
ref: 5
22 N.T

THIRD PINION

€ 0.00

6

TA2424
ref: 6
27 N.T

TOP PINION COMP.

€ 0.00

7

TA24242
ref: 7

TOP PINION BUSH

€ 0.00

8

TA2431
ref: 8
20 N.T

DRIVE SHAFT

€ 0.00

9

TA2441
ref: 9
TA 11156 34 N.T

LOW GEAR COMP.

€ 0.00

9

TA2441A
ref: 9
TA 11156 33 N.T

LOW GEAR COMP.

€ 0.00

10

TA24412
ref: 10

LOW GEAR BUSH

€ 0.00

11

TA2442
ref: 11
28 N.T

SECOND GEAR

€ 0.00

12

TA2443
ref: 12
23 N.T

THIRD GEAR

€ 0.00

13

TA2451
ref: 13

TOP PINION THRUST WASHER

€ 0.00

14

SB2461
ref: 14

THRUST WASHER

€ 2.50

15

TA2462
ref: 15

SET CIRCLIP

€ 0.00

16

SB2464
ref: 16

THRUST ADJUSTER WASHER

€ 0.00

17

TA2471
ref: 17

DRIVE SHAFT OIL SEAL

€ 2.50

18

TA2481A
ref: 18

COUNTER SHAFT OIL SEAL

€ 0.00

19

TA2482
ref: 19

DRIVE SHAFT BUSH

€ 0.00

20

TA2491
ref: 20

COUNTER SHAFT OIL CUP

€ 0.00

21

TA2492
ref: 21

DRIVE SHAFT OIL CUP

€ 0.00

22

SB2511
ref: 22
14 N.T

DRIVE SPROCKET

€ 0.00

22

TA2511S15
ref: 22
15 N.T

DRIVE SPROCKET

€ 24.50

23

TA2512
ref: 23

DRIVE SPROCKET DISTANCE COLLAR

€ 0.00

24

TA2520
ref: 24
#428X118L

DRIVE CHAIN ASSY.

€ 0.00

25

AAM4120
ref: 25
#428

DRIVE CHAIN JOINT COMP.

€ 0.00

26

SB2591
ref: 26

PRIMARY PINION SET NUT

€ 0.00

27

SB2592
ref: 27

DRIVE SPROCKET SET WASHER

€ 0.00

28

JK6304NS
ref: 28

SLOTTED BEARING

€ 0.00

29

RC06103
ref: 29

6X10 ROLLER

€ 0.00

30

SS0512
ref: 30

5X10 SCREW

€ 0.00

all assemblies
