STARTER DYNAMO

ref

part #

description

quantity

1

TA3111
ref: 1

STATOR ASSY

€ 0.00

2

TA311110
ref: 2

RIGHT CONTACT POINT ASSY

€ 0.00

3

TA311112
ref: 3

OIL FELT COMP.

€ 0.00

4

TA311121
ref: 4

CONDENSOR COMP

€ 0.00

5

TA311131
ref: 5

BRUSH COMP.

€ 0.00

6

TA311132
ref: 6

BRUSH SPRING

€ 0.00

7

TA3111401
ref: 7

NEUTRAL LEAD CORD

€ 0.00

8

TA3111402
ref: 8

FIELD COIL LEAD CORD

€ 0.00

9

TA3111403
ref: 9

DYNAMO LEAD CORD

€ 0.00

10

TA3111404
ref: 10

MOTOR LEAD CORD

€ 0.00

11

TA3111405
ref: 11

BATTERY LEAD CORD

€ 0.00

12

TA3111406
ref: 12

IGNITION LEAD CORD (A)

€ 0.00

13

TA3111407
ref: 13

IGNITION LEAD CORD (B)

€ 0.00

14

TA3111408
ref: 14

WIRE HARNESS TUBE

€ 0.00

15

TA311151
ref: 15

WIRE HARNESS BUSH

€ 0.00

16

TA311171
ref: 16

MOTOR LEAD CORD TERMINAL ASSY

€ 0.00

17

TA311172
ref: 17

TIMING MARK PLATE

€ 0.00

18

TA311175
ref: 18

TERMINAL PLATE

€ 0.00

19

TA311190
ref: 19

LEFT CONTACT POINT ASSY.

€ 0.00

20

TA3112
ref: 20

ARMATURE COMP.

€ 0.00

21

TA3113
ref: 21

GOVERNOR ASSY.

€ 0.00

22

TA31131
ref: 22

GOVERNOR SPRING

€ 0.00

23

SC3191
ref: 23

STATOR SET SCREW

€ 0.00

24

TA3193
ref: 24

WIRE HARNESS BUSH

€ 0.00

25

TA3194
ref: 25

ROTOR SET BOLT

€ 0.00

26

TA3196
ref: 26

ROTOR SET WASHER

€ 0.00

27

KW033
ref: 27

3MM WOODRUFF KEY

€ 2.00

28

SN0406
ref: 28

4X6 SCREW

€ 1.00

29

SN0408
ref: 29

4X8 SCREW

€ 0.00

30

WM041
ref: 30

4MM PLANE WASHER

€ 0.00

31

WS04
ref: 31

4MM PLANE WASHER

€ 2.00

32

WS06
ref: 32

6MM SPRING WASHER

€ 2.50

33

WS10
ref: 33

10MM SPRING WASHER

€ 2.00
