FRAME - OIL TANK - REAR FENDER

ref

part #

description

quantity

1

4110025000019
ref: 1

FRAME

€ 0.00

2

4461125000
ref: 2

OIL TANK

€ 14.50

3

4465105000
ref: 3

CAP,OIL TANK

€ 4.00

4

4466105000
ref: 4

GASKET,OIL TANK CAP

€ 6.00

5

4466205001
ref: 5

OIL TANK CAP GASKET (B)

€ 6.00

6

4464004000
ref: 6

OIL INSPECTION PLATE

€ 1.00

7

4464111000
ref: 7

LENS,INSPECTION

€ 1.50

8

0928023001
ref: 8

O RING(D:3,ID:23)

€ 2.00

9

0916805001
ref: 9

GASKET(5X9.5X1) (NAS)

€ 2.00

10

0211105168
ref: 10

SCREW

€ 2.50

11

4482025000
ref: 11

OIL TANK HOLDER

€ 0.00

12

0111106128
ref: 12

BOLT

€ 2.00

13

0832121068
ref: 13

LOCK WASHER

€ 2.50

14

0946200040
ref: 14

BAND

€ 4.50

15

4483125000
ref: 15

CUSHION

€ 0.00

16

0932109001
ref: 16

CUSHION

€ 1.50

17

4711125000159
ref: 17

COVER,FRAME,RIGHT

€ 12.00

17

4711125000185
ref: 17

COVER,FRAME,RIGHT

€ 12.00

18

0211106168
ref: 18

CROSS HEAD SCREW

€ 2.50

19

0916006019
ref: 19

WASHER(6.5X16X1.2)

€ 1.50

20

6814125000
ref: 20

RH COVER EMBLEM

€ 5.00

21

4159125000
ref: 21

PLATE,ENGINE MOUNTING

€ 4.50

22

0111208168
ref: 22

BOLT

€ 2.00

23

0832121088
ref: 23

LOCK WASHER

€ 2.00

25

6311025000159
ref: 25

FENDER,REAR

€ 0.00

25

6311025000185
ref: 25

FENDER,REAR

€ 0.00

26

0112108168
ref: 26

BOLT

€ 2.00

27

0832211088
ref: 27

WASHER

€ 2.00

28

0832121088
ref: 28

LOCK WASHER

€ 2.00

29

0910006026
ref: 29

BOLT

€ 2.50

30

0832221068
ref: 30

WASHER

€ 2.00

31

0832121068
ref: 31

LOCK WASHER

€ 2.50

32

6341125000
ref: 32

MUD GUARD,REAR FENDER

€ 5.00

33

0214105108
ref: 33

SCREW

€ 2.50

FRAME - OIL TANK - REAR FENDER

all assemblies
