FRONT FORK

ref

part #

description

quantity

1

5110025111019
ref: 1

DAMPER SET

€ 0.00

2

5113025601
ref: 2

TUBE,OUTER,RIGHT

€ 0.00

3

5114025601
ref: 3

TUBE,OUTER,LEFT

€ 0.00

4

5111025010
ref: 4

TUBE,FORK,INNER

€ 129.50

5

5115025010
ref: 5

NUT,FORK OUTER TUBE

€ 19.50

6

5115225010
ref: 6

BUSHING,GUIDE

€ 6.00

7

5115407010
ref: 7

O RING,OIL SEAL LWR

€ 7.00

8

5118125010
ref: 8

O-RING,FORK INNER TUBE

€ 2.50

9

5117325010
ref: 9

SEAL,DUST

€ 10.00

10

5141025010
ref: 10

STEM,STEERING

€ 34.00

11

5117125010
ref: 11

SPRING

€ 13.50

12

5117225010
ref: 12

GUIDE,FRONT FORK SPRING C

€ 2.50

13

5117625010
ref: 13

SPACER,SPRING

€ 0.00

14

5153025600
ref: 14

BRACKET COMP,HEADLAMP

€ 0.00

15

5154025600
ref: 15

BRACKET,HEADLAMP,LEFT

€ 0.00

16

5155307110
ref: 16

CUSHION,HEADLAMP BRACKET

€ 1.50

17

5155120210
ref: 17

SEAT,HEADLAMP BRACKET

€ 4.00

18

5118303010
ref: 18

GASKET,DRAIN,PLUG (NAS)

€ 3.00

19

0211104088
ref: 19

CROSS HEAD SCREW

€ 1.50

20

5132525010019
ref: 20

STEERING STEM HEAD

€ 35.50

21

5621112111019
ref: 21

HOLDER,HANDLEBAR

€ 0.00

22

5135125010
ref: 22

CAP,FRONT FORK

€ 16.50

23

5145305110
ref: 23

CLIP,BRAKE CABLE

€ 4.50

24

0211106108
ref: 24

SCREW, CENTER SHAFT

€ 1.50

25

0832121068
ref: 25

LOCK WASHER

€ 2.50

26

5135120010
ref: 26

BOLT,FORK INNER TUBE

€ 25.00

27

5145115110
ref: 27

BOLT,FORK INNER TUBE F

€ 0.00

28

0832121108
ref: 28

LOCK WASHER

€ 2.00

29

0122108307
ref: 29

BOLT

€ 2.50

30

0832121088
ref: 30

LOCK WASHER

€ 2.00

31

5135622010
ref: 31

WASHER,STEERING STEM

€ 0.00

32

5163125000
ref: 32

NUT,STEERING

€ 4.00

33

5161120000
ref: 33

RACE,STEERING,INNER,UPPER

€ 5.50

34

5161108000
ref: 34

RACE,STEERING,INNER,UPPER

€ 10.50

35

5162125000
ref: 35

LACE,STEERING OUTER UPR

€ 7.50

36

0611106004
ref: 36

BALL

€ 1.50

37

0611108004
ref: 37

STEEL BALL

€ 1.50

38

5164325000
ref: 38

COVER,STEERING,UPPER

€ 4.50
