TRANSMISSION

ref

part #

description

quantity

1

2412125102
ref: 1
N.T.=12

SHAFT,COUNTER

€ 32.00

2

2422125100
ref: 2
N.T.=14

GEAR,SECOND DRIVE

€ 41.00

3

2423125100
ref: 3
N.T.=19

GEAR,THIRD DRIVE

€ 20.00

4

2424125102
ref: 4
N.T.=14&19

GEAR,FOURTH DRIVE

€ 35.00

5

2413025100
ref: 5

SHAFT,DRIVE

€ 56.00

6

0928909001
ref: 6

OIL SEAL

€ 6.00

7

2431025100
ref: 7
N.T.=30

GEAR,FIRST DRIVEN

€ 14.50

8

2432125100
ref: 8
N.T.=23

GEAR,SECOND DRIVEN

€ 33.50

9

2433125100
ref: 9
N.T.=23

GEAR,THIRD DRIVEN

€ 18.50

10

2434025100
ref: 10
N.T.=18

GEAR,FOURTH DRIVEN

€ 28.50

11

2461125100
ref: 11
N.T.=23

5TH DRIVEN GEAR

€ 19.50

12

0938017001
ref: 12

CIRCLIP

€ 2.00

13

0916017001
ref: 13
17X29X1(0.67X1.14X0.04)

WASHER

€ 3.00

14

0939914002
ref: 14

KNOCK RING

€ 1.50

15

0938026001
ref: 15

RING,SNAP

€ 2.00

16

0821112241
ref: 16

WASHER

€ 2.00

17

0938025003
ref: 17

RING,SNAP

€ 3.00

18

0916015021
ref: 18
15X24X1(0.59X0.94X0.04)

WASHER

€ 1.50

19

0811362050
ref: 19

BEARING

€ 20.50

20

0928330005
ref: 20

SEAL,OIL(30X44X6)

€ 6.00

21

0611110004
ref: 21

BALL

€ 0.00

22

2760014011
ref: 22
#428X112?

CHAIN ASSEMBLY,DRIVE

€ 128.00

23

2751120200
ref: 23
N.T.=14

SPROCKET,ENGINE

€ 25.00

24

0918025026
ref: 24
25X30X13.5(0.98X1.18X0.53)

SPACER ENGINE SPROCKET 25X30X13.5

€ 6.00

25

0928025001
ref: 25

O RING(D:1,ID:24.5)

€ 2.50

26

0916725003
ref: 26

WASHER

€ 7.50

27

0914024004
ref: 27

NUT

€ 4.50

28

2424225160
ref: 28

BUSHING,FOURTH DRIVE GEAR

€ 18.50

29

0938017005
ref: 29

CIRCLIP

€ 1.50
