CYLINDER - CRANKCASE

ref

part #

description

quantity

1

1111125000
ref: 1

HEAD,CYLINDER

€ 55.00

2

1114125000
ref: 2

GASKET,CYLINDER HEAD (NAS)

€ 4.50

3

0914008005
ref: 3

NUT (8MM)

€ 1.50

4

0832211088
ref: 4

WASHER

€ 2.00

5

1121125000
ref: 5

CYLINDER

€ 139.50

7

1124125000
ref: 7

GASKET,CYLINDER (MCA)

€ 3.50

8

0910808028
ref: 8

BOLT,STUD

€ 5.50

9

1130125802
ref: 9

CRANKCASE SET

€ 135.00

11

1148125000
ref: 11

GASKET,CRANKCASE (MCA)

€ 6.50

12

0920613001
ref: 12

PIN

€ 2.50

13

0211206808
ref: 13

SCREW 6X80

€ 3.00

14

0211206708
ref: 14

SCREW 6X70

€ 3.00

15

0211206558
ref: 15

SCREW

€ 2.50

16

0211206508
ref: 16

SCREW

€ 2.50

17

0211206408
ref: 17

SCREW

€ 2.00

18

0211206358
ref: 18

SCREW (6X35)

€ 2.50

19

0930907008
ref: 19

GROMMET

€ 2.00

20

0934305018
ref: 20
L.=180(7.09)

HOSE

€ 28.50

23

0910010025
ref: 23
10SCREW,L.=115(4.53)

BOLT

€ 1.50

24

0910010060
ref: 24
10SCREW,L.=120(4.72)

BOLT 10X120

€ 3.50

25

0910010059
ref: 25
10SCREW,L.=105(4.13)

BOLT

€ 0.00

26

0831211108
ref: 26

NUT

€ 2.50

27

0832211108
ref: 27

WASHER

€ 2.50

28

0832121108
ref: 28

LOCK WASHER

€ 2.00

29

0948200003
ref: 29
NGK,B 77HC

SPARK PLUG

€ 2.00

30

3350110801
ref: 30

CAP,SPARK PLUG

€ 29.50

31

3354111000
ref: 31

SEAL,SPARK PLUG

€ 5.00

32

3354251000
ref: 32

SPARK PLUG CAP HIGH TENSION CORD SEAL

€ 4.50

33

0924710001
ref: 33

PLUG

€ 3.00

34

0916810002
ref: 34

GASKET(10X14X3.6) (NAS)

€ 2.00

35

0930907009
ref: 35

GROMMET

€ 6.00

36

0934305031
ref: 36
L.=220(8.66)

HOSE

€ 13.00

37

1115125000
ref: 37
O.D.= 13.5(0.53),H.=14(0.55)

PAD,CYLINDER HEAD

€ 5.00

38

1115116400
ref: 38
O.D.=15(0.59),H.=15(0.59)

PAD,CYLINDER HEAD

€ 8.00

CYLINDER - CRANKCASE

all assemblies
